GRACO 104266 - Zinc Plated Air Regulator, 1/2"(F) Inlet/Outlet, 0-250 PSI, 1/2 NPT(Fbe)

Air pressure regulator with multiple outlets for connecting equipment, gauges, or ball valves. Provides accurate adjustment of air pressure for process control in finishing applications. Features zinc-plated construction for durability and corrosion resistance.

Specifications

• Flow Rate: 2.5 (90) CFM at m³/min (100 psi)
• Thread: 1/2 npt(fbe)
• Max Working Pressure: 0-250 PSI (0-17.2 bar, 0-1.72 MPa)
• Material: Zinc-plated
• Gauge: 1/4(f) gauge ports
• Swivel Connection: 1/2 90° swivel(f) x 3/8(m)
• Bushing Size: 1/2 x 3/8

Features

• 1/2 NPT threaded connections
• Designed specifically for GRACO pumps
• Precise air pressure regulation
• Multiple outlets for connecting equipment, gauges, or ball valves
• Accurate adjustment of air pressure for process control
• Zinc-plated construction for corrosion resistance

Applications

• Air pressure control for pneumatic pumps
• Industrial pumping applications
• Sealant and adhesive dispensing systems
• Air preparation and control systems
• Finishing equipment pressure regulation
• Process control applications

Compatible Equipment

• President pumps
• Monark pumps

Related Parts

• 206197
• 107142
• 107141
• 223815
• 205712
• 207651
• 171937 - 1/2(f) regulator
• 104815 - 1/8(f) regulator
• 110318 - 1/4(f) regulator
• 110147 - 1/4(f) regulator

Kit Contents

• 203716 - 1/2 90° swivel(f) x 3/8(m)
• 202858 - 1/2 swivel(f) x 3/8(f)
• 202156 - 1/2 x 3/8 bushing, gauge
• 223815 - 1/2 swivel, ball valve, gauge

Part of GRACO's air controls and lubrication accessories line for ram pump systems Part of GRACO's Air Preparation and Controls product line. Can also order nipple 162505 separately. Reference number 25 in the diagram. Manual 308167 contains detailed parts breakdown for this air regulator.

Reference Manuals

• 336833 (Page 49)
• 345020 (Page 35)
• 306479 (Page 7) Evenflo Automatic Pressure Control
• 306520 (Page 7) Fire-Ball 300 and Fire-Ball 425 Drum or Tank Supply Pumps
• 306706 (Page 11) Stationary Airless Paint Sprayer 30:1 President Hydra-Spray
