GRACO 108190 - Back Mount Low Pressure Air Gauge, 0-100 PSI Range, 1/8" NPT

Back mounted air gauge with black enamel case for accurate pressure monitoring in pneumatic systems. Features NPT connections and clear pressure display for consistent process control in air tools and equipment applications.

Specifications

• Thread: 1/8 in NPT
• Max Working Pressure: 0-7 bar (0-100 psi)
• Material: Black enamel case
• Mount Type: Back mount
• Connection Options: 1/8 in NPT and 1/4 in NPT
• Mounting: Back mount
• Scale: 0-7 bar, 1/4 in NPT

Features

• Pressure monitoring capability
• Designed for air regulation systems
• Compatible with Merkur ES equipment
• Black enamel case for durability
• Back mount configuration
• Low pressure range suitable for air monitoring

Applications

• Air pressure monitoring
• Spray gun air regulation
• Industrial coating applications
• Air pressure monitoring in spray finishing systems
• Compressed air system pressure indication
• Paint spray equipment air supply monitoring

Compatible Equipment

• GRACO Merkur ES systems
• 15T499 Air Regulator

Related Parts

• 15T499 - Air Regulator
• 110436
• 100960
• 101689
• 110435 - Bottom mounted gauge 0-100 psi
• 100860 - Bottom mounted gauge 0-200 psi
• 101689 - Back mounted gauge 0-200 psi

Listed as part of the air regulation assembly (callout 4) along with the 15T499 Air Regulator on the Merkur ES system Part of GRACO's low pressure air gauge family with multiple connection size options available Part of GRACO's air accessories line for accurate pressure regulation and economical air pressure regulation solutions

Reference Manuals

• 344893 (Page 1)
• 345020 (Page 78)
• 3J0419EN (Page 12)
• 3J0419EN-A (Page 11)
• 307517 (Page 10) Spring-Operated and Air-Operated, High Pressure Mastic Fluid Regulators
