GRACO 222892 - Viscount Hydraulic Motor w/ Dura-Flo 1800 Lower, 3 PTFE/2 Leather Packings, 2600 PSI
The rugged pump lower construction with Severe Duty rods and cylinders reduces downtime and extends the interval between repairs. The simple construction makes service and repair fast and easy. The efficient hydraulic powered piston makes these pumps the ideal choice for factory and outdoor mobile use, even at below freezing temperatures.
- Clean, quiet operation with no airborne contamination
- Up to three times more energy efficient than comparable compressed air systems
- Positive displacement, 2-ball piston design provides uniform and easily controlled delivery
- Reduce routine maintenance and cut repairs time in half of comparable pump lowers
- Eliminate downtime without ice build-up
Additional Specifications
- Max Working Pressure: 18 MPa, 179 bar (2600 PSI) max fluid working pressure
- Series: Series B
- Maximum Air Input Pressure: 10 MPa, 103 bar (1500 PSI)
- Pump Model: Viscount
- Air Pressure: 1450 PSI
- Cycle Rate: 25 cycles/min
- Sound Pressure Level: 88 dB(A)
- Sound Power Level: 103 dB(A)
| Application | Supply |
| Compatible Material | Waterborne, Solventborne, High Solids, Xirallic, CARC, Metallics, Topcoats, Stains, Varnish |
| Fluid Inlet Size (in) | 2 |
| Fluid Inlet Thread Gender | Female |
| Fluid Inlet Thread Type | NPT |
| Fluid Outlet Size (in) | 1-1/2 |
| Fluid Outlet Thread Gender | Male |
| Fluid Outlet Thread Type | NPT |
| Fluid Section Type | 2-Ball |
| Material | Carbon Steel |
| Maximum Flow Rate (GPM) | 6.8 |
| Maximum Hydraulic Fluid Inlet Pressure (psi) | 1500 |
| Maximum Intermittent Cycle Rate (CPM) | 60 |
| Maximum Operating Temperature (°F) | 150 |
| Maximum Working Pressure (MPa) | 6.9 |
| Maximum Working Pressure (psi) | 1000 |
| Portable | Non-Portable |
| Pump Ratio | 26:1 |
| Standards Met | ATEX, CE |
| Type | Hydraulic Piston Pump |
| Wetted Material | Carbon Steel |
Related Parts
Kit Contents
- 235345 - HYDRAULIC MOTOR, Viscount
- 184595 - ADAPTER, connecting rod
- 184096 - NUT, coupling
- 184278 - WRENCH, packing nut
- 222796 - PUMP, displacement
- 106166 - NUT, hex; M16 x 2.0
- 184596 - ROD, tie; 315 mm (12.40 in.) shoulder to shoulder
- 184130 - COLLAR, coupling
Part number 222892 is listed as Series B with Viscount pump model. No ratio is specified (shown as dash). This appears to be a different series from the XL10000 models which are all Series A with 47:1 ratio. Some parts are included in Connection Kit 222976, which may be purchased separately. See 307158 for hydraulic motor parts and pages 28 & 29 for pump displacement parts. Tested in accordance with ISO 3744
