GRACO 248421 900 PSI Clean Line Filter Assembly Pump Mount
CleanLine Filter Systems filter new lubricants and anti-freeze at the pump outlet. CleanLine Filter Systems ensure clean product delivery in piped oil and anti-freeze systems
For use with Fire-Ball 300 5:1 or lower ratio oil pumps
- 99.9% efficient at 14 microns
- Spin-on filter system with intergrated pressure relief
Features:
- Removes contamination that can cause excessive wear and damage to engines, transmissions, differentials, gear boxes and other precision components
- Filtration of contaminants reduces engine wear and increases fuel efficiency
- Filters particulate 2 to 5 times smaller than typical automotive oil filters
- High flow filtering will not reduce system performance
- No bypass, all oil passes through the filter membrane
- Quick and easy filter replacement
Compatible Equipment
- Fire-Ball 300 5:1 or lower ratio oil pumps
- petroleum-based oils
- synthetic oils
- anti-freeze mixtures (must use CleanLine 1800 filters)
- Fire-Ball 425 6:1 pump
- Fire-Ball 425 10:1 pump
Related Parts
Reference Manuals
Specifications:
| Max Working Pressure |
CleanLine 900 - 900 psi (62 bar) CleanLine 1800 - 1800 psi (124 bar) |
| Outlet |
3/4 - 14 npt |
| Filtration Efficiency |
CleanLine 900 - ß14 = 1000 (ISO 16889)* CleanLine 1800 - ß10 = 1000 (ISO 16889)** |
| Wetted Parts |
CleanLine 900 - zinc plated steel, filter media† CleanLine 1800 - aluminum, filter media† |
| Weight (dry) |
7 lb (3.18 kg) |
| Typical Applications |
Car dealerships, fleets, mining/construction, fast lube, in plant, municipal, military |
| Typical Fluids Handled |
Synthetic motor oils, petroleum based oils, hydraulic oils, gear oils, transmission fluid, anti-freeze |
*For particle sizes 14 micron and larger, fitration is 99.9% efficient
**For particle sizes 10 micron and larger, filtration is 99.9% efficient †The filter media is compatible with petroleum-based fluid and most phosphate esters, water/oil emulsions and high water content fluids
