GRACO 557494 - Trabon MX Divider Valve - Tie Rod Nut

Tie Rod Nut designed for Trabon MGO Divider Valve systems. Essential spare part for securing tie rods in multi-section divider valve assemblies, ensuring proper valve operation and maintenance capabilities.

Features

• Tie rod fastening component
• Designed for M60 cycle indication systems
• Ensures secure assembly of tie rod sections
• Secures tie rods in MX divider valve assemblies
• Compatible with all MX section configurations
• Essential component for multi-section valve construction

Applications

• Progressive lubrication systems
• Tie rod divider valve assemblies
• M60 cycle indication switch installations
• Multi-point lubrication distribution
• Industrial machinery lubrication
• Automated grease dispensing systems

Compatible Equipment

• M60 Cycle Indication Switch systems
• Tie rod assemblies (8-section, 9-section, 10-section, 11-section configurations)
• MX-25S through MX-150S working sections
• MX-25T through MX-150T working sections
• MX w/Cycle Pin variants
• 3-10 section tie rod assemblies

Related Parts

• 560596 - 8-Section Tie Rod - Lower
• 560604 - 8-Section Tie Rod - Upper
• 560597 - 9-Section Tie Rod - Lower
• 560605 - 9-Section Tie Rod - Upper
• 560598 - 10-Section Tie Rod - Lower
• 560606 - 10-Section Tie Rod - Upper
• 560599 - 11-Section Tie Rod - Lower
• 560607 - 11-Section Tie Rod - Upper
• 563269 - Cycle Switch, SPDT, Bracket Assembly
• 557761 - Replacement Switch for 563269

This is a fastening component specifically for tie rod assemblies used with M60 cycle indication switch systems This is a hardware component used in conjunction with tie rods to assemble multi-section MX divider valve systems. Required quantity depends on the specific valve assembly configuration. This is listed as requiring 2 nuts per tie rod in the tie rod assemblies. Part of the MGO Divider Valve spare parts family.

Reference Manuals

• 339427 (Page 22)
• 340800 (Page 12)
• 312497 (Page 33) Trabon Divider Valves .
