GRACO 563226 - Trabon Replacement Rupture Indicator, 1/8-27 NPSF w/ O-Ring, 6400 PSI

Trabon replacement rupture indicator designed for MH divider valve applications where lube system pressures exceed 2,500 psi. Features high pressure disc that ruptures during lube line blockage, forcing indicator pin to protrude and locate the blockage while backing up through system to trip switch and shut system off. Includes O-ring seal for reliable performance.

Specifications

• Thread: 1/8-27 NPSF
• Max Working Pressure: 441 bar
• Memory Feature: yes
• O Ring Seal: yes
• Disc Color: Pink
• Replacement Disc: 557427 (509-282-000)
• Configuration: w/O-Ring
• Replacement Disc Diameter: 3/8 in
• Replacement Disc Part Number: 557427

Features

• Memory function retains indication after pressure event
• O-ring seal for leak-proof operation
• Visual pressure indication
• High pressure rating of 441 bar
• High pressure rupture disc (6,400 psi)
• Visual indication of system blockage via protruding pin

Applications

• MS lubrication systems
• MH lubrication systems
• MXP lubrication systems
• High-pressure monitoring applications
• MH divider valve applications
• High pressure lubrication systems over 2,500 psi

Compatible Equipment

• MS systems
• MH systems
• MXP systems
• MH divider valves
• Trabon lubrication systems
• MH Divider Valves

Related Parts

• 563229 (193 bar)
• 563221 (255 bar)
• 563222 (317 bar)
• 563224 (379 bar), 557427 (441 bar replacement disc), 557425 (379 bar replacement disc), 557424 (317 bar replacement disc), 557423 (255 bar replacement disc), 557422 (193 bar replacement disc)
• 563228 (2,800 psi)

Part of the MS, MH and MXP Rupture Indicators with Memory and O-Ring Seal family. Replacement discs available separately. When fault is corrected, the disc must be replaced and pin reset manually. Part of the Trabon Performance Indicators product line. Rupture Indicator for MH Divider Valves Only. Used on MH divider valve applications where lube system pressures exceed 2500 psi (17 MPa, 172 bar). High pressure from the lube line blockage causes a disc to rupture. The lubricant then forces an indicator pin to extend, showing the blockage. The high pressure backs up through the system and trips a switch that turns the system off. When the fault is corrected, the disc must be replaced and the pin reset manually.

Reference Manuals

• 339427 (Page 23)
• L15401EN-C (Page 3)
• 312497 (Page 39) Trabon Divider Valves .
