GRACO 563257 - Reset Indicator w/Memory, 2000 PSI, 1/8 NPSF w/O-Ring & Divider Valves
2,000 PSI reset performance indicator designed for monitoring triplex pump systems. This reset indicator provides visual confirmation of pump cycles and system performance, essential for maintaining optimal operation in professional frac applications with G3 Max DMS Grease and MSP Series Progressive systems.
Easy information on blocked lines, high system pressure or blocked bearings.
- Provides quick troubleshooting tool with visual indication
- No tools for reset or parts to replace after indication
- Easy information on blocked lines, high system pressure or blocked bearings
Additional Specifications
- Max Working Pressure: 138 bar
- Memory Function: yes
- O Ring Seal: yes
- Reset Capability: performance indicator with reset function
- Indicator Type: reset performance indicator
| Application | On-Road Vehicles, Off-Road Equipment |
| Compatible Material | Oil, Grease |
| Connection Size (in) | 0.125 |
| Indicator Type | Reset Indicator with Memory |
| Maximum Working Pressure (MPa) | 14 |
| Maximum Working Pressure (psi) | 2000 |
| Thread Type | NPSF |
| Type | Reset Indicator |
Features
- Memory function for tracking pressure events
- O-Ring seal for reliable sealing
- Reset capability
- High pressure rating of 138 bar
- 2,000 PSI pressure rating
- Reset performance indicator
Applications
- Pressure monitoring in spray systems
- Equipment maintenance tracking
- Safety monitoring applications
- Triplex pump monitoring
- Frac operations
- G3 Max DMS grease systems
Compatible Equipment
- MS series equipment
- MH series equipment
- MXP series equipment
- G3 Max DMS pump systems
- MSP Series Progressive
- Triplex pump configurations
Related Parts
Part of the MS, MH and MXP Reset Indicators with Memory and O-Ring Seal family, offering pressure monitoring with memory function This part is included as quantity 3 in both the 12 VDC and 24 VDC G3 Max DMS Grease / MSP Series Progressive Triplex Kits. It works with time-based monitoring systems with optional RPM input count and downloadable system monitoring capabilities. This component is included as quantity 5 in both the 12 VDC and 24 VDC quintuplex kits, indicating it's used for monitoring multiple points in the system. Part of GRACO's time-based monitoring system with optional RPM input count and downloadable system monitoring.
