GRACO 563956 - Blowout Disc Kit - (25) Orange, 2050 PSI, 3/8", 3/8" Diameter

Blowout disc package for rupture-to-atmosphere indicators that provide pump protection and visual indication of excessive system pressure. The pressure disc ruptures at a predetermined pressure setting, venting lubricant to the atmosphere and relieving high pressure in MH divider valve applications.

Specifications

• Thread: 3/8 in Diameter
• Max Working Pressure: 2,050 PSI
• Disc Color: Orange
• /li>
• Tolerance: ± 20%
• Diameter: 3/8 in.

Features

• Predetermined pressure rupture setting
• Visual indication of excessive system pressure
• Vents lubricant to atmosphere when activated
• Relieves high pressure in system
• Color-coded for easy identification

Applications

• MH divider valve applications
• Pump protection systems
• High pressure lubrication systems
• Systems where pressure relief is critical

Compatible Equipment

• Rupture-to-atmosphere indicators
• 3/8 in diameter fittings
• MH divider valve systems
• GRACO pumps with Rupture-to-Atmosphere Indicators

Related Parts

• 563952 (Yellow
• 1
• 450 PSI)
• 563953 (Red, 1,750 PSI)
• 563954 (Orange, 2,050 PSI)
• 563955 (Red, 1,750 PSI)
• 563957 (Aluminum, 2,350 PSI)
• 563958 (Pink, 2,650 PSI)
• 563959 (Blue, 2,950 PSI)
• 563960 (Purple, 3,250 PSI)
• 563961 (Brown, 5,000 PSI)
• 563952 - Blowout Disc (Black, 900 PSI)

Kit Contents

• 25 Orange blowout discs rated for 2,050 PSI

Part of rupture-to-atmosphere indicator system. Discs greater than 2,350 psi have a tolerance of ± 20%. Used in conjunction with complete assembly and replacement disc components. Standard on all GRACO pumps. When pressure reaches predetermined setting, the pressure disc ruptures, venting lubricant into the atmosphere and relieving pressure. All pressures have a tolerance of ± 500 psi (3.4 MPa, 34.5 bar)

Reference Manuals

• L15401EN-C (Page 3)
• 312497 (Page 40) Trabon Divider Valves .
