GRACO 248097 - Mini Fire-Ball 225 3:1 Universal Size Oil Pump w/ Suction Tube & Bung Adapter, 540 PSI

You can't afford down time, especially when your shop is small and your work force depends on equipment performance. The Mini Fire-Ball 225 is an engineered design with fewer moving parts, which means less wear out, and reduced downtime and more profit for your business.

The Mini Fire-Ball 225 3:1 is perfect for medium pressure, low volume oil applications.

• Durable - Thick cast aluminum air motor housing offers unmatched durability.
• Fewer Repairs - Fewer moving parts in the air motor assembly means less downtime and low repair cost.
• Extended Seal Life - In-line pump design aligns the air motor piston and fluid piston rods to maximize seal life.
• Reduce Downtime - Displacement rods have minimal wear due to a proprietary Graco manufacturing process.
• Superior Sealing - Non-metallic poppet valves offer positive sealing performance, even with contaminated "dirty" air environments for long life without repair.
• Reduced Icing - Large air porting design provides efficient use of compressed air supply for continuous pump operation and reduced icing.
• Corrosion-Resistant - Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

Additional Specifications

• Max Working Pressure: 540 PSI (3.7 MPa, 37 bar) Maximum Fluid Working Pressure
• Capacity: 16 gallon and 55 gallon
• Type: Fire-Ball pump
• Pump Series: Fire-Ball 225

Compatible Equipment

• 16 gallon systems
• 55 gallon systems
• 55-Gallon Open Drum Model 246906 - Mini Fire-Ball 225, 3:1 55 Gallon Oil Pump - Cover-Mounted Package, 24M263
• 16-Gallon Open Drum Model 246904 - Mini Fire-Ball 225, 3:1 16 Gallon Cover Mounted Oil Pump Package, 24M262
• 55-Gallon Closed Drum Model 246907 - Mini Fire-Ball 225, 3:1 55 Gallon Oil Pump - Bung Mounted Package, 24M264, 225 Pound Fluid Dispense Package

Related Parts

• 203872 - Fire-Ball 300 Series 5:1 Oil Pump, 16 Gallon Drum Size - for Cover Mount
• 222095 - Fire-Ball 425 Series 10:1 55 Gallon Drum Size Oil Pump - Bung Mount
• 222065 - Fire-Ball 425 Series 10:1 55 Gallon Drum Size Oil Pump - Cover Mount
• 204254 - Fire-Ball 300 Series 5:1 Oil Pump, 55 Gallon Drum Size - for Bung Mount
• 203857 - Fire-Ball 300 Series 5:1 Oil Pump, 55 Gallon Drum Size - for Cover Mount
• 222087 - Fire-Ball 300 Series 5:1 275 Gallon Drum Size Oil Pump - Bung Mount
• 246903 - Mini Fire-Ball 225, 3:1 Portable 16 Gallon Pump Package, 540 PSI (3.7 MPa
• 24M265

Technical Data and Wetted Parts information for Fire-Ball Pumps used in these packages is provided in Instruction Manual 309868 This pump appears to be used across multiple Fire-Ball configurations for different drum sizes. The description references part 309868 for additional details. Technical Data and Wetted Parts information for Fire-Ball Pumps used in these packages is provided in the related pump manual: 309868 - 3:1 Fire-Ball 225 Pump 248097. For dispensing non-corrosive or non-abrasive lubricants only.

Reference Manuals

• 307883 (Page 1)
• 307884 (Page 1)
• 309868 (Page 1)
