GRACO 805541 - Washer Spray Tip, 25035

25 degree green spray tip designed for general cleaning applications. This tip delivers a flushing spray pattern that works like a scraper when used at a 40° angle, making it ideal for cleaning dirt from siding, sidewalks, outdoor furniture, and other surfaces. Perfect for removing paint, grease, mildew and stains from concrete or other hard surfaces.

Maximize your cleaning power by selecting the tip that best matches the maximum pressure and flow of your pressure washer. For lower pressure spraying, choose a larger size tip to maximize your flow and cleaning power.

Tips include filter with quick connect and offer heavy-duty components for long life and reliability. Can be used on sidewalks, driveways, track vehicles, muddy areas, old peeling paints and concrete surfaces.

• 15 degree Chiseling Tip

  • Works like a scraper when used at a 40° angle.
  • Stripping paint; removing grease, mildew and stains.

Additional Specifications

• Max Working Pressure: 275-345 bar
• Orifice Size: 3.5

Color	Green
Connection Size (in)	0.25
Connection Type	Quick Disconnect
For Use With	AquaMax, G-Force, G-Force II, Hydra-Clean
Material	Stainless Steel
Maximum Working Pressure (psi)	5000
Model	G-Force II
Nominal Size	25035
Orifice Diameter (in)	0.045
Series	Washer Spray Tip
Tip Angle (°)	25
Type	Pressure Washer Sprayer Tip

Features

• Rotating pressure washer tip
• 25° spray angle for medium coverage
• Compatible with G-FORCE II systems
• Precision orifice design
• 25 degree spray angle for effective cleaning
• Green color coding for easy identification

Applications

• Surface cleaning
• Paint removal
• Concrete cleaning
• General pressure washing
• General cleaning
• Cleaning dirt from siding

Compatible Equipment

• G-FORCE II 3325 HA-DD
• G-FORCE II 3230 HA-DD
• G-FORCE II 4040 HG-DD
• G-FORCE II 4040 HC-DD
• G-FORCE II 4040 HG-BD
• G-FORCE II 4040 HC-BD

Related Parts

• 805591 (0°)
• 805592 (15°)
• 805593 (25°)
• 805594 (40°)
• 244768 (4-tip set)
• 244769 (4-tip set)
• 198012 (rotating tip 275 bar)
• 198014 (rotating tip 360 bar)
• 198013 (oscillating tip 345 bar)
• 805539 - Washer Spray Tip, 00035

Part of a complete tip family with different angles (0°, 15°, 25°, 40°) and available in sets. Size 3.5 orifice for balanced flow and pressure performance. This is a 25 degree green tip with 3.5 orifice size. Part of GRACO's comprehensive tip selection system for pressure washers. This tip is included as part of the standard tip set with multiple G-Force II pressure washer models. Different pressure ratings may require specific tip variants.

Reference Manuals

• 320582 (Page 4)
• 338781 (Page 8)
• 344379 (Page 8)
• 308514 (Page 2)
• 333031 (Page 24)
