GRACO 805634 - Chemical Injector Washer Spray Tip

Chemical injector tip designed for low pressure applications with detergent systems. This specialized tip enables effective application of cleaning chemicals and detergents through pressure washing equipment.

Maximize your cleaning power by selecting the tip that best matches the maximum pressure and flow of your pressure washer. For lower pressure spraying, choose a larger size tip to maximize your flow and cleaning power.

Tips include filter with quick connect and offer heavy-duty components for long life and reliability. Can be used on sidewalks, driveways, track vehicles, muddy areas, old peeling paints and concrete surfaces.

• 40 degree Washing Tip

  • Wide spray for washing or rinsing a large area.
  • Washing vehicles, windows, aluminum siding and other delicate surfaces.

Additional Specifications

• Max Working Pressure: low pressure
• Orifice Size: 5.0
• Tip Type: Chemical Injector

Color	Black
Connection Size (in)	0.25
Connection Type	Quick Disconnect
For Use With	AquaMax, G-Force, G-Force II, Hydra-Clean
Material	Brass
Maximum Working Pressure (psi)	4000
Model	G-Force II
Nominal Size	6540
Orifice Diameter (in)	0.15
Series	Washer Spray Tip
Type	Pressure Washer Sprayer Tip

Features

• Chemical injection capability
• Precision orifice design
• Compatible with G-FORCE II systems
• Chemical injector design
• Specialized for detergent application
• Compatible with G-Force II pressure washers

Applications

• Chemical injection
• Surface cleaning
• Pressure washing applications
• Applying detergent
• Misting operations
• Rinsing applications

Compatible Equipment

• G-FORCE II 3325 HA-DD
• G-FORCE II 3230 HA-DD
• G-FORCE II 4040 HG-DD
• G-FORCE II 4040 HC-DD
• G-FORCE II 4040 HG-BD
• G-FORCE II 4040 HC-BD

Related Parts

• 805535 - Washer Spray Tip, 0003
• 805536 - Washer Spray Tip, 1503, 3.0 Orifice, Up to 5000 PSI
• 805537 - Washer Spray Tip, 2503
• 805538 - Washer Spray Tip, 4003
• 805539 - Washer Spray Tip, 00035
• 805540 - Washer Spray Tip, 15035

Part of a comprehensive tip system with multiple orifice sizes available for different flow requirements and spray patterns Part of the tip selection system for G-Force II pressure washers. Listed in the chemical injector tip category alongside standard orifice tips with various degrees and pressure ratings. This is a specialized chemical injector tip that appears to be separate from the standard colored tip angle system (0°, 15°, 25°, 40°). It's specifically designed for chemical application rather than direct cleaning.

Reference Manuals

• 320582 (Page 4)
• 338781 (Page 8)
• 344379 (Page 8)
• 309828 (Page 22)
• 333031 (Page 20)
