GRACO C17009 - Nozzle, 1/8NPT X .12 4095, 1/8", Steel

Straight-tip metal nozzle designed for general purpose bead or drop dispensing applications with manual or automatic flow guns. Features precise orifice control for accurate material placement and is compatible with hot melt guns when used with appropriate adapter.

Specifications

• Inside Diameter: 0.125 in (3.18 mm)
• Length: 1.22 ft (0.36 m)
• Thread: 1/8 in NPT(m)
• Material: steel
• Orifice Diameter: 0.125 in (3.18 mm)
• Thread Type: male NPT
• Nozzle Type: straight tip
• Orifice: 0.125 in (3.17 mm)
• Inlet Size: 1/8 NPT (m)

Features

• Steel construction for durability
• Precision machined 0.125 inch orifice
• Standard 1/8 NPT male threading
• Compact 1.22 ft length design
• Straight tip design for precise dispensing
• Metal construction for durability

Applications

• Precision dispensing applications
• Automated fluid dispensing systems
• Industrial coating applications
• Sealant dispensing
• Adhesive application
• Precision material dispensing

Compatible Equipment

• GRACO sealants and adhesives dispensing equipment
• Systems requiring 1/8 NPT male threaded nozzles
• Manual flow guns
• Automatic flow guns
• Hot melt guns (with adapter 168683 - Bushing, Nozzle)

Related Parts

• 607665 - Nozzle, 1/8 Oriface
• 161505 - Nozzle, Flow Gun
• 164799
• 168683 - Bushing, Nozzle
• C00096 - Nozzle
• C08088 - Flow Gun Nozzle - 1/4 NPT, 0.157" ID

Part of the dispense nozzle family with various orifice sizes available for different flow requirements Part of GRACO's comprehensive tip and needle selection system for sealants and adhesives equipment. Grouped with other 1/8 NPT male nozzles in the selection chart. Requires adapter 168683 for use with hot melt guns. Part of the straight-tip metal nozzle family designed for Ultra-Lite and Pyles flow guns with standard nuts unless adapter is specified.

Reference Manuals

• 300639 (Page 13)
• 336833 (Page 92)
• 309376 (Page 26)
• 310538 (Page 27)
