GRACO 109145 - 1/4" x 12" Lubrication Hose 5000 PSI, Clear Plastic, 1/8 NPT(M)

12 inch clear plastic hose designed for grease gun applications, providing flexible connection without coupler for direct attachment needs

Specifications

• Inside Diameter: 1/4 in. (6.4 mm)
• Length: 12 in (30.4 cm)
• Thread: 1/8 NPT(m)
• Max Working Pressure: 5000 PSI (350 bar) Maximum Working Pressure
• Material: clear plastic
• Configuration: without coupler
• Coupling: coupled
• Thread Type: male NPT
• Restrictor: with restrictor

Features

• Clear plastic construction for visual inspection
• 12 inch length for extended reach
• Without coupler for direct connection applications

Applications

• Grease gun extensions
• Lubrication equipment connections
• Industrial maintenance applications

Compatible Equipment

• GRACO grease guns
• Lubrication equipment requiring hose extensions
• Hose Nozzle 204204, G-Mini Kits 2000047 24 VDC
• G-Mini Kits 2004436 - AC G-Mini Kit AC

Related Parts

• 112255 - 18 in (45.8 cm) clear plastic hose without coupler
• 200325 - HYDRAULIC, coupler
• 151277 - TUBE, adapter; 2.5 in. (64 mm) long
• 100451 - COUPLING, pipe; 1/8 NPT
• 25R821 - PUMP, G-Mini, 24V, 1L, CON, DIN
• 2000646 - PUMP, G-Mini, grease, 1L, AC, CTRL, FP
• 100527 - WASHER, plain
• 104541 - NUT, lock
• 556402 - FITTING, 1/4 x 1/8 NPTF hex red
• 164815 - FITTING, adapter, tee

Listed as accessory item for grease gun equipment, part of GRACO's lubrication tool accessories This hose is part of Hose Nozzle 204204 assembly and comes pre-coupled. Used with hand grip assembly that prevents exceeding maximum bend radius. Part is included in G-Mini kit assemblies, appears as reference 14 in both kit configurations

Reference Manuals

• 339473 (Page 2) Heavy-Duty Grease Guns
• 306708 (Page 6) Lube Equipment Couplers, Adapters, Nozzles, and Z-Swivels
• 3A9512 (Page 4) G-MINI and CSP Lubrication Kits
