GRACO 111598 - Air Pressure Gauge, 160 PSI, 1/4 NPT
Specifications
- Thread: 1/4 NPT
- Max Working Pressure: 160 PSI
- Pressure Range Psi: 0-160 PSI (approximate conversion)
Compatible Equipment
- Model 244072 Air Control Assembly
- Model 918406, 5 Gallon Ram Air Control Assembly
Related Parts
- 108190 - Gauge, pressure
- G11023 - REGULATOR, pressure; 130 PSI (0.9 MPa, 9.1 bar); 1/4 NPT
Reference number 30 in the assembly diagram, quantity 1 required This is reference number 30 in the assembly diagram, quantity 1 This is a pressure gauge component used in the air control assembly, referenced as item 30 in the assembly diagram
Reference Manuals
- 310524 (Page 53) Air-Powered Ram Supply Unit
- 310525 (Page 22) Air-Powered Ram Module and
- 310526 (Page 56) Ram Supply Unit
- 3A0395 (Page 52) Stainless Steel Tank Stands
- 3A4061 (Page 25) UniXact Automated Dispense Platform, Parts
