GRACO 112001 - Needle Nozzle, 0.063", 304SS, 1/8 NPT (M)

304 stainless steel blunt-end dispense needle designed for precise application of sealants and adhesives. Features 1/8 NPT threading for secure connection and .083 orifice for controlled dispensing.

Specifications

• Outside Diameter: 0.083 in (2.11 mm)
• Inside Diameter: 0.063 in (1.60 mm)
• Length: 2.5cm
• Thread: 1/8 NPT (m)
• Material: 304 stainless steel
• Gauge: 14
• Orifice: .083
• Adapter: 168683

Features

• 304 stainless steel construction for durability and chemical resistance
• Blunt-end design for precise dispensing
• 1/8 NPT male threading for secure connection
• .083 orifice for controlled flow
• Precision bead or drop deposit capability
• 304 stainless steel construction for durability

Applications

• Sealant dispensing
• Adhesive application
• Precision fluid dispensing
• Precision bead dispensing
• Drop deposit applications
• Sealants and adhesives dispensing

Compatible Equipment

• Equipment accepting 1/8 NPT male threaded needles
• Cold melt guns (not compatible with hot melt guns)
• 224906 - Stainless Dispense Dynamite Valve, 1/8 NPT(F) Fluid Inlet/Outlet, Series A Dispense Valve

Related Parts

• 112000 - Nozzle, Needle
• 112002 - Nozzle, Needle
• 112003 - Nozzle, Needle
• 112004 - Nozzle, Needle
• 112005 - Nozzle, Needle
• 112006 - Nozzle, Needle
• 112007 - Nozzle, Needle
• 690399 - Needle, Disp Metal 7Ga 1/4 NPT
• 690403 - Needle, Disp Metal 12Ga 1/4NPT
• 690405 - Needle, Disp Metal 14Ga 1/4NPT

Part of GRACO's 304 SST blunt-end dispense needle family with various orifice sizes available Do not use with hot melt guns. Requires adapter 168683. Additional needle nozzle sizes are available as accessories. See page 12.

Reference Manuals

• 336833 (Page 92) Single Component Catalog - Buyer's Guide and Specifications
• 308266 (Page 10) DynaMite Dispense Valves
