GRACO 113764 - Air Regulator, 3/8 NPT(F) Inlet & Outlet, 5-150 PSI (.03-0.1 MPa, 0.3-10 Bar)

AIR REGULATOR; 3/8 npt(f) inlet and outlet; 5-150 psi (.03-0.1 MPa, 0.3-10 bar) pressure range

Specifications

• Thread: 3/8 npt(f) inlet and outlet
• Max Working Pressure: 5-150 psi (.03-0.1 MPa, 0.3-10 bar)

Compatible Equipment

• Air Control Kit Part No. 238980 - Air Regulator Kit for President & Monark Cart Mount Airless Pumps, 3/8 NPT Series A
• Air Control Kit Part No. 239957 - Air Regulator Kit for President & Monark Wall Mount Airless Pumps, 3/8 NPT Series A
• Part No. 239976 - Air Regulator Kit for Monark Light Duty Cart Mount Airless Pumps, 3/8 NPSM(F) Series A
• Part No. 238939 - Air Filter/Regulator Kit for President & Monark Cart Mount Air-Assisted Pumps Series A

Related Parts

• 113911 - Air Pressure Gauge, 0-160 PSI
• 113763 - Wall Mount Clamp
• 113630 - Elbow Fitting, Street, 45 Deg
• 113333 - Ball Valve, Vented, .375
• 113767 - Pipe Adapter, 3/8 NPT(F)
• 155494 - Fitting, Swivel, 90 Degree
• 114129 - Fitting, Connector, Male
• 113777 - Fitting, Tee, Branch
• 113769 - Valve, Safety

Model 113764 Air Regulator shown in exploded view diagram. Lubricate with no. 2 lithium-base grease. Has associated Repair Kit 238917 which includes items 101 to 105 (diaphragm, valve assembly, O-rings, and spring). Kit parts are marked with asterisk and individual parts are not available separately. This part appears as component #3 in both air control kits. Repair Kit 247568 containing 2 o-rings is available for purchase separately, order 1 kit per bracket. This air regulator is included as part 3 in both air control kit assemblies shown on this page. A repair kit 247568 containing 2 o-rings is available for purchase separately, with 1 kit needed per clamp.

Reference Manuals

• 308686 (Page 8) High Volume Air Control Kits
