GRACO 222345 - Air Filter-Regulator-Lubricator (FRL) kit (2200/3400/Glutton w/ hose, bracket, gauge & swivel adapters), Zinc Plated Steel, 250 PSI, 1/2" inlet/outlet

Complete Air Filter-Regulator-Lubricator (FRL) kit designed for GRACO 2200/3400/Glutton spray systems. This comprehensive kit provides essential air preparation by filtering contaminants, regulating pressure, and lubricating air tools to ensure optimal performance and longevity of pneumatic spray equipment.

Specifications

• Thread: 1/2 inch inlet/outlet
• Max Working Pressure: 250 PSI (17.2 bar, 1.72 MPa)
• Material: Zinc-plated
• Dimensions: 40 x 33 x 12.7 cm (15.8 x 13 x 5.0 inches)
• Wetted Parts: Zinc

Features

• Complete air preparation system
• Filters contaminants from air supply
• Regulates air pressure
• Lubricates air for pump protection
• All-in-one kit solution
• Complete FRL (Filter-Regulator-Lubricator) functionality in one kit

Applications

• Glutton bellows pump systems
• Air supply conditioning
• Pump maintenance and protection
• Pneumatic spray systems
• Air tool preparation
• Industrial spray applications

Compatible Equipment

• Glutton bellows pumps
• GRACO 2200 series
• GRACO 3400 series
• GRACO Glutton systems
• Glutton pneumatic pumps
• President pneumatic pumps

Related Parts

• 208221 - Glutton Wall Bracket
• 102969 - Loctite High Strength Sealant
• 223319 - Return Tube Kit
• 208259 - 200 liter Suction Kit
• 204385 - Elevator with Fixed Mounting
• 237949 - Stainless Steel Drum Cover Kit
• 237579 - Air Control Kit
• 217074 - Zinc Manual Drain Air Filter, 1/2" NPT(F) Inlet/Outlet, 40 Micron, 250 PSI
• 206197 - Air Pressure Regulator w/ 1/2" NPT Inlet/Outlet, 1/4 Gauge Port, Tee Handle Type

Kit Contents

• Air filter unit
• Pressure regulator
• Air lubricator
• Connecting hose
• Mounting bracket
• Pressure gauge
• Swivel adapters
• Air filter
• Lubricator
• Mounting brackets
• Fittings

Listed as accessory for Glutton bellows systems. Specific technical specifications and kit contents not detailed on this page. This is a complete kit solution for air preparation needs on compatible GRACO spray systems, providing all necessary components for proper air conditioning. Complete FRL system ideal for protecting pneumatic pumps and equipment. Provides essential air preparation functions in one integrated unit.

Reference Manuals

• 344834 (Page 7) Bellows Pumps
• 344837 (Page 7) Graco 4-Ball Pump Technology
• 345020 (Page 34) Finishing Accessories
• 345092 (Page 27) Circulation Pumps
