GRACO 235462 Silver Plus Airless Spray Gun, 2 Finger Trigger, Fine Finish Flat Tip

The Silver Plus Gun is known for its durability, long life, spraying performance and comfortable design. Rated at 5000 psi (345 bar, 34.5 MPa), this is the preferred gun for high-pressure applications. Includes a 2-finger trigger and a Fine Finish Flat Tip Guard.

• Rugged Design

  • Durable forged aluminum withstands harsh work environments
  • Lighter weight than competitive guns Polished body is easy to clean
• Exclusive Needle Design

  • Factory set needle needs no trigger adjustments
  • Guaranteed for life against breakage
  • Maximum performance and long life
• Stainless Steel Fluid Tube

  • Fluid flows directly to the tip through the gun fluid tube
  • Provides the ability to spray heavier materials
  • Including high solid coatings and mastics
• Optional Light Viscosity Needle Kit
  • Provides faster shut-off to reduce spitting of light viscosity material
  • Included in Silver Plus Gun (Part No. 235462), or as an optional Needle Kit (Part No. 235475)

Compatible Equipment

• GMAX II
• GH 130 - 300

Related Parts

• 246240 - Silver Plus Airless Spray Gun, 2 Finger Trigger, RAC X 517 Switchtip, 345 Bar
• 243283 - Silver Plus Airless Spray Gun, 2 Finger Trigger, Rac 5 517 Switchtip, 1/4 NPSM
• 235460 - Flat Tip Silver Plus Airless Spray Gun, 2 Finger Trigger, 1/4 NPSM
• 235461 - Gun, Silver, Flat Tip
• 235474 - Repair Kit for Silver Plus & Flex Plus Guns- Includes Needle, Gasket & Diffuser/Seat
• 246468 - Flex Plus Airless Spray Gun, 2 Finger Trigger, RAC X
• 273334 - Stainless Silver Plus HP Airless Spray Gun, 2 Finger Trigger, 7250 PSI
• 241705 - RAC X Heavy-Duty Blue Texture Airless Spray Gun, 4 Finger Trigger

Reference Manuals

• 337554 (Page 18) Gas Airless Sprayers
• 343214 (Page 4) Airless Accessories
• 344386 (Page 4) Airless Accessories Brochure
• 344409 (Page 8) Roofing and waterproofing solutions
• 311254 (Page 3) Silver and Flex Plus Airless Spray Guns

Specifications:

Air Inlet Size (in)	1/4
Air Inlet Thread Gender	Male
Air Inlet Thread Type	NPSM
Body Material	Aluminum
Component A Inlet Size (in)	1/4
Component A Inlet Thread Type	NPSM
Component Type	Single Component
Fluid Orifice Size (in)	0.037
For Use With	High Pressure Application
Gun Activation	Manual
Gun Type	Airless Gun
Includes	Fine Finish Flat Tip Guard
Maximum Fluid Pressure (MPa)	34.5
Maximum Fluid Pressure (psi)	5000
Maximum Fluid Temperature (°F)	120
Model	Silver Plus
Purge Method	Liquid
Sound Power Level (dB(A))	87
Sound Pressure Level (dB(A))	78
Trigger Lock	Locking
Trigger Type	Two-Finger
Type	Spray Gun
