GRACO 080071 - Elbow Fitting, 90, JIC06 x 1/4 NPT, JIC06 x 1/4 NPT

Specifications

• Thread: JIC06 x 1/4NPT
• Angle: 90 degree
• Connection Type: JIC to NPT
• Fitting Type: Elbow
• Type: Male/Female (MF)
• Gender: Male/Female (MF)

Compatible Equipment

• Color Injector 3-Quart Tank Feed Kit (SK553)
• Model SN751-1A Color Injector
• Color Injector Kit Model #SK553-2A
• Assembly #SK553
• ST802 3-QT TANK
• SN751-1A COLOR INJECTOR

Related Parts

• 081076 - Brass Body Housing, Quick Disconnect, 1/4" NPT(M)
• 122991 - Adapter, JIC06 x 1/4NPT, Mm, Ss, 6K, 316
• 123112 - Fitting, T, 1/4Tube, Prestolock, Brs
• 16U447 - Lsr Hose, Assembly, 3/8X120, SS, Board, White, 3/8"
• 081076 - HOUSING, BODY, OD, 1/4NPTM, CRPLT, BRS
• 16A006 - FITTING, ELBOW, STREET, SST
• 123597 - ADAPTER, 3/8JIC X 1/4NPT

This is part of the Color Injector 3-Quart Tank Feed Kit. The fitting connects JIC06 to 1/4NPT threads in a 90-degree elbow configuration. This is a component part included in the Color Injector Metered Flow Kit. It appears to be used in the fluid connection system between the injector housing and other components. This fitting is part of the SK553 Color Injector 3-Quart Tank Feed Kit and connects components in the fluid system shown in the diagram.

Reference Manuals

• 332083 (Page 55) M4-55 Meter-Mix Dispense Systems
• 332276 (Page 43) M4-5 Meter-Mix Dispense System
• 332313 (Page 12) Fluid Automation E4-5 Meter-Mix Dispense Systems, Repair
• 332354 (Page 19) 633 Meter-Mix Dispense System, Repair
• 3A3103 (Page 48) Fluid Automation F4 Series, Kits-Accessories
