GRACO 104655 - Air Pressure Gauge, 1/8 NPT Inlet, 0-60 PSI (0-4.2 Bar)

GAUGE, air pressure; 0-60 psi (0-0.4 MPa, 0-4.2 bar); 1/8 npt inlet

Specifications

• Thread: 1/8 npt inlet
• Max Working Pressure: 0-60 psi (0-4.2 bar)
• Gauge Type: air pressure
• Measurement Range: 0-60 psi
• Metric Range: 0-0.42 MPa, 0-4.2 bar

Compatible Equipment

• 171226 - 2.5 Gal. Pressure Tank, Series C Basic Pressure Tank with Single Regulator
• 223833 - 2.5 Gal. Pressure Pot. AL construction, up to 50 psi, w/ dual regulators for fluid & air control with Dual Regulators
• Model 226951, Series B Bung Mount Adjustable Length Pump, Carbon Steel Model
• Model 218115 Unmetered Dispense Kit Series E
• 239703 - Dispense Kit Elect. Metered Metered Dispense Kit Series G

Related Parts

• 214979 - REGULATOR ASSEMBLY
• 100139 - PLUG, 1/8 npt
• 104815 - AIR REGULATOR
• 151519 - NIPPLE, hex reducing
• 181107 - TEE, reducing
• 104815 - REGULATOR, air; 0-60 psi (0-0.4 MPa, 0-4.2 bar)
• 103656 - NIPPLE, pipe; 1/8 npt
• 100030 - BUSHING, pipe; 1/4 npt(m) x 1/8 npt(f)
• 100403 - PLUG, pipe, 1/8 npt
• 104815 - REGULATOR, air pressure, 0-60 psi

This is part of the regulator assembly components and is used in both single and dual regulator configurations Reference number 120 in the parts diagram. Part is recommended to keep as spare to reduce down time. Part of AIR REGULATOR KIT item 20 which includes items 20a-20g. Listed as item 20b in the kit contents.

Reference Manuals

• 307133 (Page 8) 2.5 Gallon Pressure Tank
• 307427 (Page 16) Graco Fast-Flo Pump Operation
• 307637 (Page 7) Electronic POWERFIL Metered Dispense Pumps -Part
• 307870 (Page 4) Evacuation System Accessories
• 308167 (Page 11) Low Volume Air Regulators
