GRACO 114905 GL-1™ Grease Injectors - 5 Injectors and Manifold
Custom fit your system with Graco's adjustable GL-1 series grease injectors. Designed to meet the needs of each lube point, these systems provide years of reliable operation in the harshest operating environments.
High volume output at high pressures for the most demanding applications
Specifications:
| Adjustable | Adjustable |
| Application | In-Plant Machinery, Off-Road Equipment |
| Compatible Material | Grease |
| Compatible Metering Device | Single Line Parallel |
| Cycle Indicator | Visual |
| Dispense Outlet Size (in) | 0.13 |
| Dispense Outlet Thread Type | NPT |
| For Use With | Single Line Parallel Automatic Lubrication Systems |
| Inlet Size (in) | 3/8 |
| Inlet Thread Type | NPT |
| Maximum NLGI Grade | #2 |
| Maximum Operating Pressure (psi) | 3500 |
| Maximum Output Volume (in³) | 0.08 |
| Maximum Reset Pressure (psi) | 600 |
| Maximum Working Pressure (MPa) | 24.1 |
| Maximum Working Pressure (psi) | 3500 |
| Minimum Operating Pressure (psi) | 1850 |
| Minimum Output Volume (in³) | 0.008 |
| Outlet Size (in) | 3/8 |
| Outlet Thread Type | NPT |
| Suggested Operating Pressure (psi) | 2500 |
| Type | Grease Injector |
| Wetted Material | Carbon Steel, Stainless Steel, Copper, Fluoroelastomer |
GRACO 114905 GL-1™ Grease Injectors - 5 Injectors and Manifold
Custom fit your system with Graco's adjustable GL-1 series grease injectors. Designed to meet the needs of each lube point, these systems provide years of reliable operation in the harshest operating environments.
High volume output at high pressures for the most demanding applications
Specifications:
| Adjustable | Adjustable |
| Application | In-Plant Machinery, Off-Road Equipment |
| Compatible Material | Grease |
| Compatible Metering Device | Single Line Parallel |
| Cycle Indicator | Visual |
| Dispense Outlet Size (in) | 0.13 |
| Dispense Outlet Thread Type | NPT |
| For Use With | Single Line Parallel Automatic Lubrication Systems |
| Inlet Size (in) | 3/8 |
| Inlet Thread Type | NPT |
| Maximum NLGI Grade | #2 |
| Maximum Operating Pressure (psi) | 3500 |
| Maximum Output Volume (in³) | 0.08 |
| Maximum Reset Pressure (psi) | 600 |
| Maximum Working Pressure (MPa) | 24.1 |
| Maximum Working Pressure (psi) | 3500 |
| Minimum Operating Pressure (psi) | 1850 |
| Minimum Output Volume (in³) | 0.008 |
| Outlet Size (in) | 3/8 |
| Outlet Thread Type | NPT |
| Suggested Operating Pressure (psi) | 2500 |
| Type | Grease Injector |
| Wetted Material | Carbon Steel, Stainless Steel, Copper, Fluoroelastomer |
