Item #: 16R117
Price: $18,445.71
Call 888-654-8898
Need this Product for a Specific Application?
Use our handy finder to find the exact model for your needs.
GRACO 16R117 - 13:1 Ratio Internal Mix Chop System w/ 50ft Hose & Cart
Professional-grade 13:1 ratio internal mix chop system featuring a complete setup with 50-foot hose and cart for efficient material application. Designed for high-performance spray applications requiring precise material mixing and extended reach capabilities.
To keep material costs low, the system has been designed so that it doesn’t need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Additional Specifications
Specifications
| Air Inlet Size (in) | 1/4 |
| Air Inlet Thread Gender | Female |
| Air Inlet Thread Type | NPT |
| Component A Inlet Size (in) | 3/8 |
| Component B Inlet Size (in) | 1-5/16 |
| Component B Thread Gender | Male |
| Component B Thread Type | UN-2A |
| Fluid Inlet Size (in) | 3/4 |
| Fluid Inlet Thread Gender | Male |
| Fluid Inlet Thread Type | NPT |
| Fluid Outlet Size (in) | 3/4 |
| Fluid Outlet Thread Gender | Female |
| Fluid Outlet Thread Type | NPT |
| Hose Length (ft) | 50 |
| Includes | Hose, Cart |
| Maximum Air Inlet Pressure (psi) | 100 |
| Maximum Flow Rate (GPM) | 1.5 |
| Maximum Flow Rate (cc/min) | 5680 |
| Maximum Working Pressure (MPa) | 9 |
| Maximum Working Pressure (psi) | 1300 |
| Model | FRP |
| Overall Depth (in) | 32.5 |
| Overall Height (in) | 47.75 |
| Overall Width (in) | 29.5 |
| Series | IC |
| System Ratio | 13:1 |
| Type | Proportioning System |
| Wetted Material | Stainless Steel, Carbide, UHMWPE, PTFE, Acetal |
Features
Applications
Compatible Equipment
Related Parts
Part of comprehensive internal mix chop gun system family with various hose lengths and configurations available Part of GRACO's comprehensive 13:1 ratio system family with various hose length and configuration options available This is a complete system with cart configuration. CE and EX approved model indicated by star symbol.
