GRACO 176637 - Pin, Stop, Ball, .187" OD x 1.56" Long, Stainless Steel

Specifications

• Material: sst

Compatible Equipment

• 215932 - Pump, Displacement, Recip, Series B
• 217339 - Stainless Steel Displacement Pump 1500 PSI, Long Stroke, PTFE Packings, Series A
• 904287 - Stainless SS Pres. Pump, W1-1/2 NPT(M) Inlt, 600 PSI (4.0 MPa, Series A - Short Stroke, Modified Intake, with PTFE packings
• 254999 - 2 Ball Transfer Pump, Displacement, Recip, SS
• 224341 - Stainless Severe-Duty, Uhmwpe/PTFE Packed SS Displacement Pump, Severe-Duty UHMWPE/PTFE Packed Stainless Steel Displacement Pump

Related Parts

• 100063 - Cotter Pin, 1/6" Dia OD, 1/2"
• 101917 - Ball Bearing, 7/8" Dia., 304SS
• 105364 - Wave Spring
• 176633 - Back-Up Washer
• 176634 - Washer, Stud, Pistpn, 1.875" OD x 1.31" ID
• 176635 - Vee Packing, PTFE
• 176640 - Gland, Packing, Female
• 176642 - Piston Stud
• 176643 - Gland, Packing, Male
• 176644 - Stud, Mounting, Piston

Part of piston assembly (item 16: 215339 PISTON ASSEMBLY; sst Includes items 17-27). Listed as reference number 22 in the parts breakdown. This is a recommended 'tool box' spare part to keep on hand to reduce down time. Reference number 22 in the assembly. This part is included in Repair Kit 224401 and Optional PTFE Packing Conversion Kit 224889. Quantity required: 1

Reference Manuals

• 307430 (Page 10) Stainless Steel Displacement Pump
• 308116 (Page 22) Stainless Steel Pumps, Severe-Duty, UHMWPE/PTEE or PTFE Packed
• 308117 (Page 19) s, Stainless Steel Hydra-Clean Pumps
• 308118 (Page 21) Stainless Steel Pumps
• 308155 (Page 25) Dyna-Star Hydraulic Reciprocator and Pump
