GRACO 17H466 - LineLazer V 250SPS HP Automatic Series Self-Propelled Gas Hydraulic Airless Line
Price: with strikethrough $38,910.00
Retail Price:
Sale Price: Price $33,351.43
Item #: 17H467
Price: $39,320.00
Call 888-654-8898
Need this Product for a Specific Application?
Use our handy finder to find the exact model for your needs.
Price: with strikethrough $38,910.00
Retail Price:
Sale Price: Price $33,351.43
GRACO 17H467 - LineLazer V 250SPS HP Automatic Series Self-Propelled Gas Hydraulic Airless Line Striper, 3300 PSI
LineLazer V 250DC with 2 Automatic Guns - Professional self-propelled hydraulic airless line striper designed for high-productivity pavement marking applications. Features advanced hydraulic drive system, dual automatic guns for increased coverage, and comprehensive control systems for precise line application.
With exclusive automatic paint guns and hydraulic power, the LineLazer V 250SPS HP Automatic Series is a self-propelled system that is ideal for large, heavy-duty line striping jobs including parking lots and road jobs.
The HP Automatic Series adds enhanced features that provide contractors automatic line production capability, including skip-lines, as well as real-time job performance data for proof-of-job requirements.
Additional Specifications
Specifications
| Attachments | None |
| Compatible Material | Road-Marking Paint |
| Compatible Surfaces | Pavement, Turf |
| Engine Brand | Honda |
| Engine Model | GX390 |
| Fuel Tank Capacity (gal) | 1.4 |
| Gun Activation | 2 Automatic |
| Hopper Volume Capacity (gal) | 25 |
| Includes | Flex Plus Gun (2), LineLazer RAC 5 321 Spray Tip (2), LineLazer RAC 5 425 Spray Tip (2), LineLazer RAC 5 627 Spray Tip (2), RAC 5 Tip Guard (2), 3/8 in x 12 ft (3.7 m) BlueMax II Airless Hose, 3/8 in x 3 ft (0.9 m) BlueMax II Airless Whip Hose, TSL 4 oz (118 mL) |
| Maximum Flow Rate (GPM) | 2.5 |
| Maximum Operating Speed (mph) | 10 |
| Maximum Sound Pressure Level (dB(A)) | 89.1 |
| Maximum Speed (RPM) | 3600 |
| Maximum Tip Size (in) | 0.039 |
| Maximum Working Pressure (psi) | 3300 |
| Model | LineLazer V |
| Number of Colors | One Color |
| Number of Guns | 2 |
| Number of Hoppers | 1 |
| Number of Pumps | 1 |
| Overall Height (in) | 50.5 |
| Overall Length (in) | 73.5 |
| Overall Width (in) | 33 |
| Power Rating (HP) | 13 |
| Power Rating (kW) | 9.69 |
| Power Source | Gas Hydraulic |
| Product Series | HP Automatic |
| Pump Type | Endurance |
| Series | 250SPS |
| Type | Self-Propelled Line Striper |
| Weight (lb) | 666 |
Features
Applications
Compatible Equipment
Related Parts
Part of HP Automatic Series. Can be configured with front or rear gun mount and supports expansion up to 6 guns total. This is part of the LineLazer V 250SPS HP Automatic series. The unit supports multiple gun configurations with different maximum tip sizes depending on the number of guns used. This is a complete 2-gun automatic LineLazer system in the V 250DC series, designed for medium to high-volume line striping applications with dual gun capability for increased productivity.
Reference Manuals
GRACO 17H467 - LineLazer V 250SPS HP Automatic Series Self-Propelled Gas Hydraulic Airless Line Striper, 3300 PSI
LineLazer V 250DC with 2 Automatic Guns - Professional self-propelled hydraulic airless line striper designed for high-productivity pavement marking applications. Features advanced hydraulic drive system, dual automatic guns for increased coverage, and comprehensive control systems for precise line application.
With exclusive automatic paint guns and hydraulic power, the LineLazer V 250SPS HP Automatic Series is a self-propelled system that is ideal for large, heavy-duty line striping jobs including parking lots and road jobs.
The HP Automatic Series adds enhanced features that provide contractors automatic line production capability, including skip-lines, as well as real-time job performance data for proof-of-job requirements.
Additional Specifications
Specifications
| Attachments | None |
| Compatible Material | Road-Marking Paint |
| Compatible Surfaces | Pavement, Turf |
| Engine Brand | Honda |
| Engine Model | GX390 |
| Fuel Tank Capacity (gal) | 1.4 |
| Gun Activation | 2 Automatic |
| Hopper Volume Capacity (gal) | 25 |
| Includes | Flex Plus Gun (2), LineLazer RAC 5 321 Spray Tip (2), LineLazer RAC 5 425 Spray Tip (2), LineLazer RAC 5 627 Spray Tip (2), RAC 5 Tip Guard (2), 3/8 in x 12 ft (3.7 m) BlueMax II Airless Hose, 3/8 in x 3 ft (0.9 m) BlueMax II Airless Whip Hose, TSL 4 oz (118 mL) |
| Maximum Flow Rate (GPM) | 2.5 |
| Maximum Operating Speed (mph) | 10 |
| Maximum Sound Pressure Level (dB(A)) | 89.1 |
| Maximum Speed (RPM) | 3600 |
| Maximum Tip Size (in) | 0.039 |
| Maximum Working Pressure (psi) | 3300 |
| Model | LineLazer V |
| Number of Colors | One Color |
| Number of Guns | 2 |
| Number of Hoppers | 1 |
| Number of Pumps | 1 |
| Overall Height (in) | 50.5 |
| Overall Length (in) | 73.5 |
| Overall Width (in) | 33 |
| Power Rating (HP) | 13 |
| Power Rating (kW) | 9.69 |
| Power Source | Gas Hydraulic |
| Product Series | HP Automatic |
| Pump Type | Endurance |
| Series | 250SPS |
| Type | Self-Propelled Line Striper |
| Weight (lb) | 666 |
Features
Applications
Compatible Equipment
Related Parts
Part of HP Automatic Series. Can be configured with front or rear gun mount and supports expansion up to 6 guns total. This is part of the LineLazer V 250SPS HP Automatic series. The unit supports multiple gun configurations with different maximum tip sizes depending on the number of guns used. This is a complete 2-gun automatic LineLazer system in the V 250DC series, designed for medium to high-volume line striping applications with dual gun capability for increased productivity.
Reference Manuals
