GRACO 17L282 - Motor Repair Kit, X5, X7

Replace a worn or damaged motor with genuine Graco parts. Replacement motor kit ready to install. For Magnum X5 and X7 paint sprayer models. Refer to the parts manual for your sprayer to ensure part compatibility

Specifications

Compatible Equipment

• SP200/2400 Series D Stand Sprayer
• Magnum Electric Airless Sprayers
• Magnum Project Painter Plus
• X5
• X7
• LTS15

Related Parts

• 16D682 - BRACKET, motor
• 17L086 - Repair Kit, PushPrime, X5, X7
• 17L104 - Repair Kit, Control Board Replacement, X5, X7
• 17L079 - Repair Kit Magnum Pump
• 17K541 - Kit, Repair, Enclosure, X5
• 17K542 - Kit, Repair, Enclosure, X7
• 17V782 - Pressure Control Replacement Kit for X5, X7 Paint Sprayers
• 17V783 - Magnum Prime Spray Drain Valve Kit
• 16E845 - Magnum Outlet Valve Replacement Kit
• 16E844 - Magnum Inlet Valve Replacement Kit

Reference number 5 in the parts diagram, quantity 1 This is a motor replacement kit for Magnum Electric Airless Sprayers. Instructions for motor replacement are referenced on page 4. Related kits include PushPrime Replacement (17L086), Control Board Replacement (17L104), and Pump Assembly Replacement (17L079). This is a replacement kit for Magnum sprayers. No detailed specifications or kit contents are provided on this page - only the kit description and compatible models.

Reference Manuals

• 3A3234 (Page 37) Electric Airless Sprayers, Operation, Parts
• 3A3655 (Page 1) Replacement Kits for Magnum Electric Airless Sprayers, Kit Instructions
• 3A5572 (Page 1) Replacement Kits for Magnum Project Painter Plus, X5, X7, LTS15 and LTS 17
