GRACO 2000481 - Stellair Automatic Spray Gun Alignment Tool

The Stellair Auto Alignment Tool (part number 2000481) is a patent-pending spray pattern alignment and pathing tool that ensures accurate and repeatable spray angles. This simple tool helps optimize spray gun positioning to match the part being sprayed, reducing overspray and material waste while programming finishing robots to maintain correct distance from parts for even coverage and smooth runs.

Features

• Ensures accurate and repeatable spray angle
• Patent-pending technology
• Simple operation
• Reduces overspray and material waste
• Enables precise robot programming
• Alignment tool for precise spray gun setup

Applications

• Robotic finishing operations
• Automated spray gun positioning
• Industrial coating applications requiring consistent spray patterns
• Industrial finishing applications
• Automotive finishing
• Industrial metal component finishing

Compatible Equipment

• Stellair spray guns
• Finishing robots
• Automated spray systems
• Stellair Automatic Air Spray Guns
• General Industry guns with side inlet manifold
• High wear guns

Related Parts

• 25F155 - Side Fluid Inlet Manifold (Inch)
• 25F315 - Side Fluid Inlet Manifold (Metric)
• 2000226 - Side Inlet Pan Adjustable Manifold (Inch)
• 2000230 - Rear Fluid Inlet Manifold (Inch)
• 2000231 - Rear Fluid Inlet Manifold (Metric)

Used to set the angle of the air cap so that it matches the part being sprayed and to program a finishing robot to keep the spray gun at the correct distance from the part, preventing uneven coverage and runs Part of the Stellair automatic air spray gun accessory line. Backed by GRACO's A+ Customer Service with support at (844) 241-9499. Refer to manual #407194 for more detailed information. This is an alignment and pathing tool specifically designed for use with Stellair spray gun systems to optimize automated finishing operations.

Reference Manuals

• 345208 (Page 3)
• 345208AUEN-B (Page 3)
• 407194 (Page 13)
