GRACO 2006146 - Stellair HVLP Air Spray Gun, General Industry .086" Nozzle
Stellair pressure feed spray gun designed for general industry applications, delivering precision efficiency and quality finishes. Built on aluminum gun body with stainless steel fluid components for durability and superior performance.
Pressure feed air spray gun delivers the all-star ergonomics, performance, and serviceability industrial painters need to produce stellar results.,Whether you’re a custom shop or a high volume manufacturing facility, Stellair brings industry leading finish quality to these and other applications: automotive, metal, plastic, and wood.
Additional Specifications
Specifications
| Air Inlet Size (in) | 1/4 |
| Air Inlet Thread Type | NPSM |
| Application | General Industry |
| Applicator Type | Manual |
| Compatible Material | Enamel, Epoxy, Fast-Set, High Solids, Latex, Plural-Component, Sealants, Solventborne, Urethane, Waterborne |
| Feed Type | Pressure Feed |
| Fluid Inlet Size (in) | 0.375 |
| Fluid Inlet Thread Type | NPSM |
| Fluid Orifice Size (in) | 0.086 |
| Gun Activation | Manual |
| Gun Type | HVLP Gun |
| Gun Weight (oz) | 14.5 |
| Includes | Air Cap, Needle Assembly, Nozzle |
| Maximum Air Pressure (MPa) | 0.7 |
| Maximum Air Pressure (psi) | 100 |
| Maximum Fluid Pressure (MPa) | 2.1 |
| Maximum Fluid Pressure (psi) | 300 |
| Maximum Operating Temperature (°F) | 109 |
| Model | Stellair |
| Needle Tip Material | PEEK |
| Series | Manual |
| Trigger Lock | Non-Locking |
| Trigger Type | Two-Finger |
| Type | Spray Gun |
| Wetted Parts | Stainless Steel, PEEK, Acetal, Fluoroelastomer, UHMWPE |
Features
Applications
Compatible Equipment
Related Parts
Kit Contents
Part of the Stellair ACE pressure feed gun family. The 0.086 (2.2) nozzle size with PEEK tip construction is specifically designed for general industry applications with unique atomization patterns. Part of General Industry gun model family with PEEK Tip construction and HVLP spray technology This appears to be a complete spray gun kit for General Industry HVLP applications with 0.086 inch nozzle
Reference Manuals
GRACO 2006146 - Stellair HVLP Air Spray Gun, General Industry .086" Nozzle
Stellair pressure feed spray gun designed for general industry applications, delivering precision efficiency and quality finishes. Built on aluminum gun body with stainless steel fluid components for durability and superior performance.
Pressure feed air spray gun delivers the all-star ergonomics, performance, and serviceability industrial painters need to produce stellar results.,Whether you’re a custom shop or a high volume manufacturing facility, Stellair brings industry leading finish quality to these and other applications: automotive, metal, plastic, and wood.
Additional Specifications
Specifications
| Air Inlet Size (in) | 1/4 |
| Air Inlet Thread Type | NPSM |
| Application | General Industry |
| Applicator Type | Manual |
| Compatible Material | Enamel, Epoxy, Fast-Set, High Solids, Latex, Plural-Component, Sealants, Solventborne, Urethane, Waterborne |
| Feed Type | Pressure Feed |
| Fluid Inlet Size (in) | 0.375 |
| Fluid Inlet Thread Type | NPSM |
| Fluid Orifice Size (in) | 0.086 |
| Gun Activation | Manual |
| Gun Type | HVLP Gun |
| Gun Weight (oz) | 14.5 |
| Includes | Air Cap, Needle Assembly, Nozzle |
| Maximum Air Pressure (MPa) | 0.7 |
| Maximum Air Pressure (psi) | 100 |
| Maximum Fluid Pressure (MPa) | 2.1 |
| Maximum Fluid Pressure (psi) | 300 |
| Maximum Operating Temperature (°F) | 109 |
| Model | Stellair |
| Needle Tip Material | PEEK |
| Series | Manual |
| Trigger Lock | Non-Locking |
| Trigger Type | Two-Finger |
| Type | Spray Gun |
| Wetted Parts | Stainless Steel, PEEK, Acetal, Fluoroelastomer, UHMWPE |
Features
Applications
Compatible Equipment
Related Parts
Kit Contents
Part of the Stellair ACE pressure feed gun family. The 0.086 (2.2) nozzle size with PEEK tip construction is specifically designed for general industry applications with unique atomization patterns. Part of General Industry gun model family with PEEK Tip construction and HVLP spray technology This appears to be a complete spray gun kit for General Industry HVLP applications with 0.086 inch nozzle
Reference Manuals
