GRACO 203876 - Fire-Ball 300 Series 5:1 Universal Size Oil Pump, 900 PSI

As the mainstay pump in the industry for decades, the reputation of Fire-Ball is unrivaled. Built to withstand the test of time with fewer moving parts, our flagship pump is built to extend uptime so customers can be more productive. The durable pumps are renowned for their durability, with pumps built decades ago still operating efficiently.

Install the Fire-Ball 300 5:1 in high pressure, medium volume oil transfer applications such as automotive dealerships, fast lube centers, and service shops.

• Reliable Flow - A 3 inch (76.2 mm) differential air motor and the double-acting pump design provides reliable fluid flow and accurate dispense.
• Durable - Thick cast aluminum air motor housing offers unmatched durability.
• Fewer Repairs - Fewer moving parts in the air motor assembly means less downtime and low repair cost.
• Extended Seal Life - In-line pump design aligns the air motor piston and fluid piston rods to maximize seal life.
• Reduce Downtime - Displacement rods have minimal wear due to a proprietary Graco manufacturing process.
• Superior Sealing - Non-metallic poppet valves offer positive sealing performance, even with contaminated "dirty" air environments for long life without repair.
• Reduced Icing - Large air porting design provides efficient use of compressed air supply for continuous pump operation and reduced icing.
• Corrosion-Resistant - Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

Additional Specifications

• Length: 20.7 in (526 mm)
• Thread: 3/8 in. NPT(F) air inlet, 1/2 in. NPT(F) fluid outlet
• Max Working Pressure: 900 PSI (6.2 MPa, 62 bar) Maximum Working Pressure
• Air Input Pressure: 180 PSI (1.2 MPa, 12 bar) Maximum Air Input Pressure
• Application: For pumping non-corrosive and non-abrasive greases and lubricants only
• Series: N
• Type: Universal
• Air Inlet Height: 8.9 in. (226 mm)
• Grounding Screw: included

Compatible Equipment

• Fire-Ball 300 series equipment

Related Parts

• 203857 - Fire-Ball 300 Series 5:1 Oil Pump, 55 Gallon Drum Size - for Cover Mount
• 204254 - Fire-Ball 300 Series 5:1 Oil Pump, 55 Gallon Drum Size - for Bung Mount
• 222087 - Fire-Ball 300 Series 5:1 275 Gallon Drum Size Oil Pump - Bung Mount
• 203872 - Fire-Ball 300 Series 5:1 Oil Pump, 16 Gallon Drum Size - for Cover Mount

Kit Contents

• 101
• 102
• 103
• 104
• 105
• 106
• 107
• 108
• 109
• 110
• 111
• 112

For professional use only. Part of Fire-Ball 300 pump model series. Includes items 101 to 112. Related models include 203857 (Series R, 55 gal.), 203872 (Series R, 16 gal.), 204254 (Series U, 55 gal. Bung Mount), and 222087 (Series G, 275 gal. Bung Mount) Part of a series of pumps with different overall lengths. Shown in dimensional diagram with grounding screw and specific inlet/outlet configurations.

Reference Manuals

• 306518 (Page 1) 5:1 Fire-Ball 300 Pump
• 306520 (Page 9) Fire-Ball 300 and Fire-Ball 425 Drum or Tank Supply Pumps
