GRACO 208610 - Air/Water Hose, 3/4" x 6 ft (3/4" x 3/4" End Fittings) 180 PSI, Buna-N, 3/4 NPT(M)
Air hose component for Check-Mate grease systems, designed for reliable air supply to grease pumps in industrial lubrication applications
Specifications
- Inside Diameter: 3/4 inch
- Length: 6 ft
- Thread: 3/4 NPT(m)
- Max Working Pressure: 175 PSI (12 bar) Maximum Working Pressure
- Material: Buna-n
- Hose Type: air
- Grounded: yes
Features
- Air supply hose for grease systems
- Compatible with Check-Mate pump systems
Applications
- Industrial grease lubrication systems
- Pneumatic grease pump applications
- Equipment maintenance and lubrication
Compatible Equipment
- Check-Mate Grease Pump Floor Stand Packages (all ratios 14:1 through 68:1)
- Check-Mate Grease Ram Packages (ratios 14:1, 63:1, 68:1)
- P14MCS, P26MCS, P29MCS, P55MCS, P63MCS, P68MCS pumps
- P14DCS, P26DCS, P29DCS, P50DCS, P63DCS, P68DCS pumps
Related Parts
- 115042 - 1 in x 6 ft Fluid Hose
- 244657 - 1 in x 6 ft Fluid Hose
- 205548 - 3/4" x 15ft Hose
- 208611 - Air/Water Hose, 3/4 ft, x 25 ft (3/4" x 3/4" End Fittings) 180 PSI
This air hose is a standard component across multiple Check-Mate grease system packages and is used in conjunction with fluid hoses for complete system operation Part of the Grounded 3/4 in. (19 mm) Buna-n Air Hose family with different length options This is an air hose with 3/4 inch internal diameter and 3/4 NPT male thread fittings
Reference Manuals
- 339719 (Page 2) Supply Systems
- 307276 (Page 14) Hydra Mastic Pump, 30:1 Ratio Bulldog, 55 Gallon Drum Size
- 309344 (Page 2) Stand Mount Bulk Grease Transfer Packages
- 309345 (Page 3) Bulk Grease Transfer Package
- 310524 (Page 25) Air-Powered Ram Supply Unit
