GRACO 21035- 00 - Strainer, Pick-Up, Material

Compatible Equipment

• ASME Pressure Pots 2-gallon 16M893
• ASME Pressure Pots 5-gallon 16M894
• ASME Pressure Pots, 2-gallon 16M893
• ASME Pressure Pots, 5-gallon 16M894

Related Parts

• 17440-00 (CLAMP
• grounding)
• 16D939 (FITTING
• nipple
• reducing)
• 11021-23 (PLUG
• pipe
• 1/4)
• 18470-05 (VALVE
• ball
• 2-way
• 1/4NPTf)
• RM-856-04 (FITTING
• elbow
• 1/4 NPTm x 1/4 NPTm)
• 20655-04 (FITTING
• 3/8 NPTm x 3/8 tube)
• 103347 (VALVE, safety, 100 PSI), 21462-01 (FITTING, adapter, 1/4 NPTm x 3/8 NPTf), 3165 (VALVE, ball, 2-way, 3/8 female, 3/8 male), 13867-68 (TANK LID GASKET)

Part is referenced as item 1308 in the assembly diagram. Special assembly note 1 indicates: 'To assemble strainer (1311), remove the dip tube from tank (1301). Slide strainer onto bottom end of dip tube. Hold strainer in place while positioning dip tube. Strainer should be secure on tube and pressed to bottom of tank. Tighten dip tube in place. Strainer not shown.' Part is included in Optional Solvent Pressure Pot Kits for ASME pressure pots. Reference number 1208 in the assembly diagram. Assembly note indicates to assemble strainer (1101) remove the dip tube from tank (1101), slide strainer onto bottom end of dip tube, hold strainer in place while positioning dip tube - strainer should be secure on tube and pressed to bottom of tank, then tighten dip tube in place. Part 8 in the assembly diagram. Assembly instruction mentions: 'To assemble strainer (11), remove the dip tube from tank (1). Slide strainer onto bottom end of dip tube. Hold strainer in place while positioning dip tube. Strainer should be secure on tube and pressed to bottom of tank. Tighten dip tube in place. Strainer not shown.'

Reference Manuals

• 3A2012 (Page 75)
• 3A4527 (Page 59)
• 407032 (Page 2)
