GRACO 24E008 Check-Mate 29:1 Grease Pump Floor Stand Package
Move Large Amounts of Grease Fast
Tested to outperform and outlast all other pumps on the market – with its long-life packing design and intuitive, easy-to-use controls – the NXT™ High-Flo pump is the best value for the money. Fewer parts, faster repairs, and long-lasting durability
Applications:
- Fleet services facilities
- In-plant
- Mining
Typical Fluids Handled:
Includes:
- P29DCS NXT™ Check-Mate® Air-Powered 29:1 Grease Pump without DataTrak
- 116471 1" Ball Valve
- 116648 1" Swivel Fitting
- 157785 Air Fitting Swivel
- 208390 Ball Valve at Base
- 208610 Hose Coupled 3/4" x 6ft Air/Water Hose 180PSI
- 222776 Mounting Kit
- 223952 Pump Adapter Base
- 244524 Grounding Wire Assembly with Clamp
- 244657 1" x 6 ft Fluid Hose
- NXT011 Air-Integrated Locking Control
Compatible Equipment
- NXT 3400 motor
- P29MCS pump with DataTrak
- P29DCS - NXT Check-Mate Air-Powered 29:1 Grease Pump without DataTrak
Related Parts
Reference Manuals
- 339719 (Page 2) Supply Systems
- 312863 (Page 2) Oil Pump System
Specifications:
| Fluid Pressure Ratio | 29:1 |
| Air Motor | NXT 3400 |
| Air Motor Effective Diameter | 7.5 in (191 mm) |
| Pump Lower | L250CS |
| Maximum Fluid Working Pressure | 2,900 psi (200 bar / 20 MPa) |
| Output per Cycle | 7.7 oz (218 g) |
| Air Inlet | 3/4 in NPT(F) |
| Fluid Outlet | 1 in NPT(F) |
| Air Operation Range | 0 psi to 100 psi (0 bar to 7 bar) |
| Max Recommended Pump Speed | 20 cpm |
| Cycles per Pound | 2.1 cpp |
| Cycles per Kg | 5 cpk |
| Sound Pressure Level | 77 dB(A) |
| Sound Power Level | 87 dB(A) |
| Approximate Weight | 128 lb (58 kg) |
