GRACO 24E446 - Front Head External Check Valve Kit

Front head external check valve repair kit designed for maintaining optimal performance of GRACO spray guns. This kit provides essential components for servicing the external check valve system in the front head assembly, ensuring proper fluid flow control and preventing leakage in professional spray applications.

Features

• Check valve repair kit
• Front head external configuration
• Maintains proper fluid flow control
• Prevents leakage
• Easy serviceability
• Repair kit for external check valve maintenance

Applications

• Spray gun maintenance
• Front head check valve repair
• Professional coating applications
• Industrial finishing
• RS spray gun maintenance
• External mix spray applications

Compatible Equipment

• GRACO spray guns with external mix front heads
• RS External Mix Gel Coat Guns
• RS External Mix Chop Guns
• RS spray gun systems
• GRACO RS spray gun systems
• Related spray gun models in the RS series

Related Parts

• 24E447 - Front head external check valve repair kit
• 24E443 - Front head internal check valve
• 24E444 - Internal spring check valve kit
• 24E426 - Horizontal external mix front head kit
• 24E427 - Vertical external mix front head kit
• 24E442 - Horizontal/vertical internal mix front head kit
• 24E425 - Trigger air valve kit
• 24E423 - Catalyst check valve
• 24E424 - Check valve housing kit
• 24E408 - Seat seal, 6-pack

Part of comprehensive gun repair kit system. Used specifically for external check valve maintenance in front head assemblies. Part of comprehensive RS gun parts system with multiple check valve and repair options available This is a check valve kit specifically designed for the front head external position in GRACO spray gun systems. Part of the comprehensive RS gun parts family.

Reference Manuals

• 340712 (Page 7)
• 348529 (Page 2)
• 348645 (Page 10)
• 349820 (Page 10)
• 3A0232 (Page 49)
