GRACO 24J030 - LD Series 50:1 35 lb Grease Pump - Stationary Package, 5000 PSI

GRACO 24J030 LD 50:1 Grease Pump designed for high-pressure grease dispensing applications. This stationary package pump delivers reliable performance with a 50:1 pressure ratio, capable of handling up to 35 bar (5000 PSI) working pressure. Engineered for professional lubrication systems requiring consistent grease delivery.

Stay ahead of the competition with LD Series pumps. These affordable and full-featured pumps are designed for lower-volume up to 7,000 lb./year (3175 kg./year) applications. LD pumps are fine-tuned for a compact, flexible and durable solution.

• Three Inch Air Motor - Provides more power to create better flow.
• Engineered for Durability - Patented cup and plate design eliminates the need for O-Rings that wear out faster for a more durable, longer-lasting solution.
• Modular Air Valve - Air inlet and exhaust locations are easy to configure with just four bolts for simple, hassle free installations.
• Pilot Valves - Patented self-cleaning design increases reliability in dirty air environments and minimizes pressure drop with rapid changeovers for reduced stalling and smoother flow.

Additional Specifications

• Flow Rate: 7 cycles per liter (29 cycles per gallon)
• Thread: NPT
• Max Working Pressure: 35 bar (3.5 MPa, 5000 PSI)
• Air Operation Range: 1.37 to 10.3 bar (20 to 150 PSI)
• Max Pump Speed: 120 cycles per minute
• Weight: 35 pound (15.8 kg)
• Capacity: 16 kg (35 lb)
• Grease Capacity: 35 pound (15.8 kg)
• Series: LD Series
• Ce Marking: Not CE Marked

Features

• 50:1 fluid pressure ratio for high-pressure applications
• Stationary package design for fixed installation
• 16 kg (35 lb) grease capacity
• Durable wetted parts construction
• 120 cycles per minute maximum pump speed
• Wide air pressure operating range

Applications

• Professional lubrication systems
• Industrial grease dispensing
• Stationary lubrication stations
• High-pressure grease applications

Compatible Equipment

• LD Series lubrication systems
• GRACO lubrication equipment
• NPT threaded systems
• 24G600 pump

Related Parts

• 246582 - LD 3:1 Oil Pump 200L Drum Metallic
• 246594 - LD 5:1 Oil Pump 200L Drum Metallic
• 246606 - LD 50:1 Grease Pump 180 kg
• 250549 - LD 50:1 Grease Pump 16 kg Mobile Package
• 24J031
• 24J032
• 24J033
• 24J034
• 24J035
• 25C549

Manual 3A1335 and Repair Kit Manual 3A1495 available for service support This is a stationary grease pump model in the LD Series with 50:1 pump ratio and NPT thread connections. It's part of the 35 pound capacity grease models family. Part of a series ranging from 24J030-24J032 for 35 pound models. Also referenced in fluid hose kit 24H862 compatibility list. Associated with pump model 24G600 (PUMP, 50:1, NPT, 35 pound).

Reference Manuals

• 300787 (Page 43)
• 3A1335 (Page 36)
