GRACO 24P486 - XD50 Diesel Fuel Hose Reel 1" x 75 ft, Yellow, 250 PSI

Heavy-duty XD50 fuel hose reel designed for diesel fuel dispensing applications. Features a durable yellow powder-coated finish for easy identification and corrosion resistance. Built to withstand demanding commercial and industrial fuel handling operations with reliable retraction and secure hose storage.

Graco’s XD40 and XD50 Series Hose Reels are engineered to take a beating and still reliably perform in harsh environments so it’s ready when you need it. Choose from several color options, thread types and hoses. Typical fluids handled include: Petroleum- and synthetic-based oils, diesel fuel, air, water, antifreeze and waste oil.

Ideal for rugged indoor and outdoor use in heavy-duty truck dealerships, fleet maintenance, mining maintenance, public works garages, construction vehicle maintenance, agriculture and service trucks.

• Extensive Hose Offering - Standard models come complete with factory installed hoses on the reel, large selection of optional reels to fit various applications
• Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
• Rugged and Durable Body - Heavy-duty welded spool and ribbed frame for extra strength and toughness over the long haul
• Meets Worldwide Needs - Built standard with 90° elbow with NPT threads

Additional Specifications

• Length: 75 ft (23 m)
• Max Working Pressure: 250 PSI (17 bar)
• Operating Temperature: -40°F to 180°F (-40°C to 82°C)
• Model: Model 3
• Reel Series: XD 40
• Connection Size: Model 3
• Dimension F: 17.47 in (444 mm)
• Model Dimension: Model 3

Features

• Heavy-duty XD 40 reel construction
• 250 PSI pressure rating for reliable fuel dispensing
• Wide operating temperature range from -20°F to 180°F
• Model 3 configuration with 1-inch connections
• 75-foot hose length for extended reach
• Heavy-duty XD50 reel construction

Applications

• Fuel dispensing
• Diesel fuel handling
• Commercial fuel operations
• Industrial fuel systems
• Fuel dispensing operations
• Commercial fuel stations

Compatible Equipment

• XD50 reel systems

Related Parts

• 24P485
• 24P487
• 24P488
• 24P489
• 24P490
• 24P491
• 24P492
• 24P493
• 24P494
• 24P495

Part of the XD 40 reel series specifically designed for fuel applications. Available in multiple colors (Blue, Yellow, White) with varying hose lengths and connection sizes. Part of the XD50 fuel reel series. Available in blue and white color options as well (24P485 and 24P487). Model 3 connection type provides 1 inch inlet and outlet NPT connections. Part of the XD50 fuel hose reel family. Available with various inlet hose kits and ball stop kits as accessories.

Reference Manuals

• 340979 (Page 4)
• 340979EN-D (Page 3)
• 332203 (Page 7)
• 332399 (Page 7)
• 3A2990 (Page 7)
