GRACO 24W617 - ProConnect Replacement Rod Paint Sprayer Pump Kit for Pro210ES

Replacement rod component for GRACO airless paint sprayers, designed to maintain optimal pump performance and extend equipment life. This rod is a critical wear component in the pump assembly that requires periodic replacement for consistent spray performance.

To keep material costs low, the system has been designed so that it doesn’t need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.

Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.

• Optimized Ratio Stability

  • Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
  • Precision engineered linkage offers you superior ratio control and consistent cure

• Lower Cost of Ownership

  • Easy maintenance - fewer repair parts
  • Long lasting seals mean less downtime
  • Pumps last longer between planned maintenances
  • No surge bottle necessary, less parts, solvent and resin needed to prime the pump

• Optional DataTrak™ Control

  • Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
  • Tracks cycles for preventive maintenance schedule
  • Displays real time flow rate - eliminates material waste due to worn spray tips

• Roving Management System

  • Better guides—less tangling, more uptime

• Gravity Fed Catalyst System

  • Keeps the catalyst pump primed for consistent delivery

• New Linkage and Catalyst Pump

  • Truly engineered linkage for superior ratio control
  • Allows for infinite adjustment of catalyst percentage — no tools required
  • Ensures proper catalyst percentage and optimum results
  • Variance of 1% or less

• Balanced Graco NXT® Air Motor

  • Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
  • Shortened stroke on pump for better spray pattern

• Control Panel

  • Easy user interface with all gauges in one location

• Stable, Lightweight Cart

  • Easy to maneuver
  • Strong, durable casters

Specifications:

Features

• ProConnect replacement component
• Professional-grade wear part
• Easy maintenance and serviceability
• Critical pump component
• Maintains spray consistency
• Extends equipment life when replaced regularly

Applications

• Professional painting applications
• Contractor use
• High-volume spray applications
• Airless paint spraying
• Maintenance and repair of GRACO sprayers
• Electric paint sprayers

Compatible Equipment

• RentalPro 210 PC (Part #176303)
• RentalPro 230 PC (Part #176407)
• 190 PC Express
• 390 PC
• Ultra 390 PC Pro
• Ultra Max II 490 PC Pro

Related Parts

• 24W619 - Cylinder
• 246429 - Intake Seal Kit
• 244194 - Repair Kit
• 17C488 - Replacement Pump
• 246429 - Intake Seat Kit
• 17C487
• 17J552
• 18G300
• 24G429

This is a wear part/replacement component for RentalPro series paint sprayers. Used in conjunction with cylinder 24W619 as part of the pump assembly. This rod (24W617) is used across multiple GRACO airless sprayer models in both small and mid-sized electric categories. Part of the pump assembly requiring periodic maintenance. This page shows 24W617 in the replacement parts compatibility chart but does not provide detailed individual part specifications or description. The part appears to be compatible with multiple electric sprayer models in the GRACO lineup.

Reference Manuals

• 338781 (Page 9) RentalPro Sprayers
• 343211 (Page 14) Gas Airless Sprayers
• 344381 (Page 11) Electric Sprayers
• 344406 (Page 11) Electric Sprayers
• 334599 (Page 19) ProConnect Endurance Displacement Pump, Repair
