GRACO 24Z714 - Kit, 5 Pin Npn w/ Heat Shrink, M12

Specifications

• Length: 12 in.
• Thread: M12
• Voltage: 10-32 VDC
• Control Type: single control
• Signal Type: NPN
• Connector Type: M12 to 5 Pin
• Connector 1: Straight 5 Pin
• Connector 2: M12
• Polarity: NPN
• Power Requirement: 10-32 VDC power supply

Compatible Equipment

• 10-32 VDC single control PNP proximity switch
• proximity switch
• BH-mini connection

Related Parts

• 24Z715 - Cable, M12 to 3 Pin, NPN Adapter
• 24Z716 - Cable, M12 to 4 Pin, NPN Adapter
• 24Z719 - Cable, M12 to 4 Pin, PNP
• 24Z720 - Cable, M12 with PNP LED to Flying Leads, PNP, 90°, 5m
• 26A782 - Cable, M12 with PNP LED to flying Leads, PNP, 90°, 10m
• 25M604 - Cable, M12 with PNP LED to Flying Leads, PNP, Straight
• 25M602 - Cable, M12 with NPN LED to Flying Leads, PNP, Straight
• 25M603 - Cable, M12 with NPN LED to M12, PNP Straight, 5m
• 25U234 - Cable, M12 with NPN LED to M12, PNP, Straight, 0.6m
• 24Z715

NPN adapter cable connects to the PNP switch and inverts the signal to NPN for the controller. Not approved for use in European explosive atmosphere locations. Cable kit that allows switch to function as NPN but requires a DC power source. Includes blue shrink wrap for reconfiguring already installed proximity switch cable. Female End has M12 Micro Connector Face, Male End has BH-Mini Connector Face with 5-pin configuration.

Reference Manuals

• 3A4481 (Page 1)
