GRACO 25M081 - ToughTek CM40 Continuous Mixer System, 60hz, Water Based Materials

The GRACO 25M081 ToughTek CM40 Continuous Mixer is a high-performance mixing system designed for continuous mixing applications. This unit delivers 300 bags per hour material delivery capacity with precise 18.0 gpm (70.8 lpm) flow rate capability, making it ideal for high-volume commercial and industrial mixing operations.

Although identical in size and function as the MP20, the MP40 has double the output and can pump up to 200 bags per hour of selfleveling underlayment. The larger motor and pump make the MP40 an excellent fit for contractors looking for a high production solution.

Ideal for self-leveling underlayment, non-shrink grout and pre-blended toppings

• Compact, easy to maneuver
• Easy to operate with variable speed control
• 425 PSI (29 bar) pumping pressure
• Vertical pumping distance: 60 feet (18 m)
• Horizontal pumping distance: 200 feet (61 m)
• Rugged hopper with bag breaker – holds six 50-lb (23 kg) bags
• Power MP40: 230V, 30A, 3-ph
• Output MP40: up to 50 lpm (100 cu ft/hr)

Additional Specifications

• Flow Rate: 18.0 gpm (70.8 lpm)
• Max Working Pressure: N/A
• Material: Water Based Materials
• Maximum Particle Size: 5/16 in (8 mm)
• Power Input: 240V, 30A, 1PH
• System Weight: 440 lb (200 kg)
• Manual: 3A4350
• Material Output: Up to 110 bag per hr
• Chemical Compatibility: Water Based Materials
• Maximum Flow Rate: 18.0 gpm (70.8 l/min)

Features

• Continuous mixer design for uninterrupted operation
• High capacity 300 bags per hour material delivery
• 18.0 gpm maximum flow rate
• Handles particles up to 5/16 inch
• 240V single phase power operation
• Water-based material compatibility

Applications

• High-volume continuous mixing operations
• Commercial construction projects
• Industrial material mixing applications
• Water-based material processing
• High-volume commercial mixing projects
• Continuous production environments

Compatible Equipment

• ToughTek CM40 system components
• Water-based materials
• Water based materials
• CM40 System

Related Parts

• 25M530 (CM20)
• 25M050 (P40)
• 25M032 (P30HT)
• 25M062 (MP40)
• 25M530
• 25M032
• 25M132
• 25M050
• 25M630, CM20 System components

Part of the ToughTek continuous mixer family. System designed for water-based materials only. Part of the CM40 Continuous Mixer product line, designed for heavy-duty continuous mixing applications with the highest output capacity in the product family. Part of the ToughTek CM40 continuous mixer family, designed for high-capacity water-based material processing applications

Reference Manuals

• 3J0254EN-A (Page 3)
• 3J0260EN-A (Page 3)
• 3J0423EN-B (Page 4)
• 3J0423EN-C (Page 4)
• 3A4350 (Page 2)
