GRACO 25M712 - Steerable Carriage Kit

Steerable Carriage Kit designed for enhanced maneuverability and control of RoadPak striping systems, allowing operators to easily navigate and position equipment for precise line striping applications

Features

• Steerable design for improved maneuverability
• Compatible with multiple RoadPak systems
• Provides steerable control
• Enhances equipment maneuverability
• Integrates with RoadPak control systems
• Improves operator control and precision

Applications

• Road marking
• Pavement striping
• Traffic line painting
• Road striping operations
• Pavement marking
• Line striping applications

Compatible Equipment

• RPS Option 3 (25D270)
• RPS Option 4 (25D271)
• RPS Option 7 (25D274)
• RPS Option 8 (25D275)
• RPS Option 11 (25D278)
• RPS Option 12 (25D279)

Related Parts

• 25D270 - RoadLazer RoadPak System Option 3, w/ Rear Seat Kit & Steerable Carriage
• 25D271 - RoadLazer RoadPak System Option 4, w/ RoadView HD Camera System, Rear Seat Kit, & Steerable Carriage
• 25D274 - RoadLazer RoadPak 2-Pump System Option 7, w/ Rear Seat Kit & Steerable Carriage
• 25D275 - RoadLazer RoadPak 2-Pump System Option 8, w/ RoadView HD Camera System, Rear Seat Kit, & Steerable Carriage
• 25D278 - RoadLazer RoadPak 2-Pump System Option 11, w/ 1350 lb Bead Tank, Rear Seat Kit, & Steerable Carriage
• 25D279 - RoadLazer RoadPak 2-Pump System Option 12, w/ 1350 lb Bead Tank, RoadView HD Camera System, Rear Seat Kit, & Steerable Carriage
• 25D280 - RoadLazer RoadPak HD System Option HD1, w/ 1350 lb Bead Tank
• 25D281 - RoadLazer RoadPak HD System Option HD2, w/ 1350 lb Bead Tank & RoadView HD Camera System
• 25D282 - RoadLazer RoadPak HD System Option HD3, w/ 1350 lb Bead Tank, Rear Seat Kit & Steerable Carriage
• 25D283 - RoadLazer RoadPak HD System Option HD4, w/ 1350 lb Bead Tank, RoadView HD Camera System, Rear Seat Kit, & Steerable Carriage

This page shows compatibility only - detailed specifications not provided in this chart format Part of GRACO's custom RoadPak system components that can be configured to meet specific striping needs. Listed under control systems category suggesting it provides enhanced steering/directional control capabilities. Part of the CE Kit for RoadLazer RoadPak Line Striping System. Reference number 13 in the system.

Reference Manuals

• 344405 (Page 7) RoadLazer Brochure
• 3A1658 (Page 1) CE Kit for RoadLazer RoadPak Line Striping System
• 3A5384 (Page 2) RoadLazer RoadPak & RoadPak HD Line Striping System
• 3A5387 (Page 33) Programmable Skipline Controller for RoadLazer RoadPak Line Striping System
• 3A5407 (Page 1) Steerable Carriage Kit for RoadLazer™ and RoadPak™ Line Striping Systems, 25M712
