GRACO 25V477 - Level Sensor Low Level, 30 ft
Low Level 9 m Float for GRACO Fluid Defender system - essential component for monitoring fluid levels and preventing overfill or pump run away situations in tank management applications
Specifications
- Length: 9 m
- Float Length: 9 m (30 ft)
- Minimum Specific Gravity: 0.75
- Amp Rating: 0.1 amp
- Maximum Fluid Viscosity: 2,000 centipoise
- Temperature Range: 14°F to 122°F (-10°C to 50°C)
- Minimum Detectable Tank Level: 2 in (5.1 cm)
- Minimum Head Space: 5.5 in (2.54 cm)
Features
- Low level detection capability
- 9 meter float length for deep tank applications
- Compatible with motor oil, waste oil, ATF, antifreeze, diesel, and WWS
- Works with high viscosity fluids up to 2,000 centipoise
- Wide temperature operating range
- Low amp rating for energy efficiency
Applications
- Tank level monitoring and control
- Overfill prevention
- Pump run away protection
- Bulk fluid management
- Motor oil storage systems
- Waste oil collection
Compatible Equipment
- GRACO Fluid Defender (25V654)
- GRACO Pulse Fluid Defender (25V655)
- Fluid Defender controller systems
Related Parts
- 25V475
- 25V476
- 25V478
- 25V479
- 25V482
Part of the GRACO Fluid Defender family that can control and monitor up to 5 tanks using air solenoids to increase control and defend from overfill or pump run away
Reference Manuals
