GRACO 262940 - Wp Light Pressure Monitor Kit

Take control of protective coatings projects with the XP Pressure Monitor Kit. This wall-powered monitoring system with light tower ensures your GRACO XP70 Plural-Component Sprayer operates on-ratio by automatically shutting down when off-ratio conditions occur, protecting coating quality and preventing material waste.

Specifications

• Power Type: electric wall power
• Compatible Motor: XLE5500 air motor
• Unit Compatibility: XP units
• Power Source: wall powered

Features

• Local Control Module displays A & B pressures while spraying
• Air solenoid motor for automatic shutdown
• Light tower indicates sprayer status and alarms
• Electrical box with pressure transducers
• Automatic detection of off-ratio conditions
• Alarm code display on LCM screen

Applications

• Protective coatings projects
• Plural-component spraying applications
• Industrial coating operations requiring ratio monitoring
• Hazardous location spray applications
• Industrial coating operations requiring pressure monitoring
• Professional spray systems with XP units

Compatible Equipment

• GRACO XP70 Plural-Component Sprayer
• XP units with XLE5500 air motor
• XP system

Related Parts

• 262942 - Pressure monitor kit, air powered with light tower
• 16H378 - Membrane shield, 10-pack
• 16J717 - Protective bag
• 16G410 - Pressure Transducer Tee Adapter
• 3A1331 - Manual - XP Pressure Monitor Kit
• 262942 - Tp Light Pressure Monitor Kit

Kit Contents

• Local Control Module
• Air solenoid to motor
• Light tower
• Electrical box
• Pressure transducers

Not approved for use in explosive atmospheres. Detects running out of material, pump cavitation, packing failures, leaks in valves or fittings, and plugged filters. Part of GRACO's pressure monitoring system for hazardous location applications Automatically monitors difference between A and B pressures when at spray pressure and shuts down the system if there is a problem. These kits do not carry the EX mark.

Reference Manuals

• 348546 (Page 2)
• 3J0679EN (Page 14)
• 3J0679ENEU (Page 14)
• 3A0420 (Page 82)
• 3A1331 (Page 2)
