GRACO 288211 - International Rear Port Manifold

Specifications

• Mounting Hole Spacing: 0.875 in. (22.23 mm)
• Overall Height: 1.375 in. (34.93 mm)
• Hole Diameter: 0.205 in. (5.21 mm)
• Edge Distance: 1.010 in. (25.65 mm)
• Side Spacing: 0.400 in. (10.16 mm)

Compatible Equipment

• International markets

Related Parts

• 288160 - Rear Port Manifold, North America
• 288217 - North America Manifold w/ Side Fluid Ports
• 288218 - International Manifold w/ Side Fluid Ports
• 288221 - Manifold, Bottom Inlet (In)
• 288224 - High Pressure Air Assisted Manifold w/ side fluid ports & manual fan adjustment valve
• 24C343 - High Pressure Air Assisted Manifold, International
• 288160 - Manifold, Rear Fitting, Inch

Kit Contents

• 101 - MANIFOLD, aluminum (1)
• 103 - FITTING, fluid path (2)
• 15J003 - #5 JIC (quantity not specified)
• 105 - 116475 - SCREW, SHCS, M4 x 12 (2)
• 106 - 120353 - O-RING, PTFE (2)
• 107 - 15J077 - O-RING, PTFE (2)
• 110 - 103253 - SCREW, set (2)
• 112 - 120538 - FITTING, tube, air inlet; 6 mm OD tube x 1/8 npt(m) (1)
• 113 - 114246 - SCREW, set, hex soc (1)

This is the International version of the rear port manifold. Assembly instructions include applying sealant to threads and mating faces of manifold and fittings/plugs, with specific torque requirements of 30-42 in-lb (3.4-4.7 N•m) and 110-130 in-lb (12.3-14.7 N•m) for different components. Order separately; not included with gun (See Parts, page 25). Part of the Gun Manifolds family with various port configurations including side fluid ports, bottom fluid ports, and high pressure air assisted options. Mounting hole layout dimensions provided for installation reference. Part 288160 and 288211 appear to be variants of the same rear port manifold design.

Reference Manuals

• 311052 (Page 29) Automatic G40 Air-Assisted Spray Gun
• 3A8553 (Page 31) PerformAA™ Auto Air Assist Spray Guns
