GRACO 563054 Single Ball Check Valves - 35 psi Nominal Cracking PSI, 7/16-20 inch SAE , SS body/steel ball, 3,500 psi
Single Ball Check Valve
35 psi nominal cracking pressure
7/16-20 inch SAE (M) x 7/16-20 inch SAE (F)
steel body/ball
3,500 psi max
Compatible Equipment
- NSP, MHH and MXAXP divider valves (outlet ports)
Related Parts
- 563055 - Single Ball Check Valves - 35 psi Nominal Cracking PSI, 9/16-18" SAE (M x F), SS body/steel ball, 3, 500 psi
- 563195 - Single Ball Check Valve - 10 psi Nominal Cracking Pressure, 1/8 in NPT(F) (M) x 1/8 in NPSF (F), Steel, 5, 000 psi
- 563196 - Single Ball Check Valve - 35 psi Nominal Cracking Pressure, 1/8 in NPT(F) (M) x 1/8 in NPSF (F), Steel, 5, 000 psi
- 563197 - Single Ball Check Valve - 125 PSI Nominal Cracking Pressure, 1/8 in NPT(F) (M) x 1/8 in NPSF (F), Steel, 5, 000 PSI
- 563198 - Single Ball Check Valve - 250 psi Nominal Cracking Pressure, 1/8 in NPT(F) (M) x 1/8 in NPSF (F), Steel, 5, 000 psi
- 563199 - Single Ball Check Valve - 15 PSI Nominal Cracking Pressure, 1/8 in NPSF (F) x 1/8 in NPT(F) (M), Steel, 5, 000 PSI
- 563200 - Single Ball Check Valve - 35 psi Nominal Cracking Pressure, 1/8 in NPSF (F) x 1/8 in NPT(F) (M), Steel, 5, 000 psi
- 563201 - Single Ball Check Valve - 60 psi Nominal Cracking Pressure, 1/8 in NPSF (F) x 1/8 in NPT(F) (M), Steel, 5, 000 psi
Reference Manuals
Specifications:
| Application | Compressor Equipment |
| Ball Material | Steel |
| Body Material | Stainless Steel |
| Compatible Material | Oil, Grease |
| Inlet Size (in) | 7/16 |
| Inlet Thread Type | SAE |
| Maximum Cracking Pressure (psi) | 35 |
| Maximum Working Pressure (MPa) | 24.1 |
| Maximum Working Pressure (psi) | 3500 |
| Number of Balls | Single Ball |
| Outlet Size (in) | 7/16 |
| Outlet Thread Type | SAE |
| Type | Check Valve |
