GRACO 563176 - Valve Relief Indicator O-Ring 3000 PSI, 1/8" Npsf w/o-Ring

Automatic Relief Indicator that pinpoints lube line blockage while allowing the lube system to continue supplying lubrication to points that are not blocked. Used primarily in secondary divider valves, this indicator detects excessive pressure created by line blockage and moves a piston to enable lubricant escape through a vent. When blockage is restored, the spring resets the piston, allowing the lube system to keep operating even when a lube point is blocked.

Specifications

• Thread: 1/8 in NPSF w/O-Ring
• Max Working Pressure: 207 bar
• Material: Carbon Steel, 303 SST
• Tolerance: ±24%

Features

• O-ring seal design
• Automatic relief indication
• Visual system monitoring
• Performance indication capability
• Standard relief to atmosphere
• Compatible with Pro and Max pump configurations

Applications

• Pressure relief monitoring
• System safety indication
• Equipment protection
• Hydraulic fracturing operations
• High-pressure pumping systems
• Industrial fluid transfer

Compatible Equipment

• MJ series equipment
• MS series equipment
• MH series equipment
• MXP series equipment
• Pro Pump Kit
• Max Pump Kit

Related Parts

• 563170 - Valve Relief Indicator O-Ring 750 PSI, 1/8" NPTF
• 563171 - Valve Relief Indicator O-Ring 1000 PSI, 1/8" Npsf w/o-Ring
• 563172 - Valve Relief Indicator O-ring 1250 psi
• 563173 - Valve Relief Indicator O-ring 1500 psi
• 563174 - Valve Relief Indicator O-ring 2000 psi
• 563175 - Valve Relief Indicator O-ring 2500 psi
• 563261 - Reset Indicator w/ Memory, 3000 PSI, 1/8 NPSF w/ O-Ring - MH, MS, MXP Divider Valves
• 563061 - Double Ball Check Valve 48 PSI Nominal Cracking PSI, 1/4" NPSF (F) x 1/4" NPSF (F), SS Body/FKM Ball, 7500 PSI
• 563251 - O-Ring Seal Msp & Mhh Divider Valve Smagnetic Visual Cycle Indicator
• 125910 - G3 Pump Mounting Bracket

Part of a complete series of automatic relief indicators with O-ring seals available in pressure ratings from 52 bar to 207 bar Order quantity for Triplex systems: 3 units, for Quintuplex systems: 5 units. Use specifically with Pro or Max Pump Kit configurations. Pressure ratings are stamped on the body of the indicator. Color coding system previously used spring retainer colors for pressure identification (reference Table 3). A separate pressure switch connected to audible or visual alarm should be used to warn of high pressure.

Reference Manuals

• 339427 (Page 22) Automatic Lubrication Systems
• 352295 (Page 20) Fracturing Equipment Selection Guide
• L15401EN - C (Page 2)
• 312497 (Page 39) Trabon Divider Valves .
