GRACO 563207 - Single Ball Check Valve - 35 PSI Nominal Cracking Pressure, 1/4 in NPT(F) (M) x 1/4 in NPSF (F), Steel, 5, 000 PSI

Single Ball Steel Check Valve designed for use in hydraulic or lubrication systems with pressures up to 5000 PSI. Features positive seal to prevent leakage and backflow with compact and easy to install design. Uses standard ball and spring principle with symbol stamped on body indicating flow direction.

Specifications

• Length: 0.937 inches (23.7 mm)
• Thread: NPT
• Max Working Pressure: 5000 PSI maximum operating, 60 PSI nominal cracking pressure
• Material: Steel body, steel spring, steel ball
• Hex Size: 0.56 inches (14.2 mm)
• Weight: 28g (1oz) approximate
• Max Temp Pipe Thread: 500°F (260°C)
• Max Temp Sae Orb Bspp: 250°F (121°C)
• Valve Type: INLET
• Type: check valve

Features

• Outlet check valve functionality
• Compatible with baseplate manifolds
• Available in multiple thread configurations
• Positive seal prevents leakage and backflow
• Compact and easy to install
• Standard ball and spring principle

Applications

• Baseplate manifold lubrication systems
• Industrial lubrication applications
• Trabon Modu-Flo systems
• Hydraulic systems
• Lubrication systems
• Systems with pressures up to 5000 PSI

Compatible Equipment

• Trabon Modu-Flo baseplate manifolds
• NPT GRACO systems
• NPT Lubriquip systems
• NSP spray valves
• MHH spray valves
• MXMAP spray valves

Related Parts

• 509-360-030 (NPT Lubriquip equivalent)
• 563211 (System Fill Check Valve)
• 563179 (Standard Blowout Assembly)
• 563186 (Tubed Blowout Assembly)
• 557864 (Standard Dry Pressure Gauge)
• 557866 (Liquid-Filled Pressure Gauge)
• 563195 - Single Ball Check Valve - 10 PSI Nominal Cracking Pressure, 1/8 in NPT(F) (M) x 1/8 in NPSF (F), Steel, 5, 000 PSI
• 563196 - Single Ball Check Valve - 35 PSI Nominal Cracking Pressure, 1/8 in NPT(F) (M) x 1/8 in NPSF (F), Steel, 5, 000 PSI
• 563197 - Single Ball Check Valve - 125 PSI Nominal Cracking Pressure, 1/8 in NPT(F) (M) x 1/8 in NPSF (F), Steel, 5, 000 PSI
• 563198 - Single Ball Check Valve - 250 PSI Nominal Cracking Pressure, 1/8 in NPT(F) (M) x 1/8 in NPSF (F), Steel, 5, 000 PSI

Part of the Trabon Modu-Flo L12000 series accessories. Cross-references to NPT Lubriquip part number 509-360-030. Used as outlet check valve in baseplate manifold configurations. Check valve is installed with symbol on body facing in direction of flow. Incoming flow pushes ball from valve seat, compressing spring and permitting lubricant to flow through. When flow stops, spring expands to reseat ball creating positive seal. Part appears as item 7 in the MSA-10 Air Operated Pump parts diagram with quantity of 1

Reference Manuals

• L12000EN - D (Page 6)
• L15825EN - F (Page 1)
• 332023 (Page 12) MSA-10 and MSA-100 Air Operated Pump -Installation
