GRACO 563232 - Reset Indicator w/ Memory, 500 PSI, 1/8 NPT(F) - MJ, MH, MS, MXP Divider Valves
Reset indicator with memory function designed for MJ, MS, MH and MXP divider valves. Provides visual indication when system pressure drops below set point and retains indication until manually reset, ensuring operators are aware of pressure loss events even after pressure is restored.
Easy information on blocked lines, high system pressure or blocked bearings.
- Provides quick troubleshooting tool with visual indication
- No tools for reset or parts to replace after indication
- Easy information on blocked lines, high system pressure or blocked bearings
Additional Specifications
- Thread: 1/8 NPTF
- Max Working Pressure: 34 bar (approximately 500 PSI)
- Compatible Valve Series: MJ, MH, MS, MXP
| Application | On-Road Vehicles, Off-Road Equipment |
| Compatible Material | Oil, Grease |
| Connection Size (in) | 0.125 |
| Indicator Type | Reset Indicator with Memory |
| Maximum Working Pressure (MPa) | 3 |
| Maximum Working Pressure (psi) | 500 |
| Thread Type | NPTF |
| Type | Reset Indicator |
Features
- Memory function retains indication until manual reset
- Visual pressure drop indication
- Designed for divider valve systems
- Low pressure threshold detection
Applications
- Progressive divider valve monitoring
- Lubrication system pressure monitoring
- Automatic lubrication equipment
- Industrial machinery lubrication systems
Compatible Equipment
- MJ Divider Valves
- MS Divider Valves
- MH Divider Valves
- MXP Divider Valves
Related Parts
- 563231 - 17 bar Reset Indicator
- 563233 - 52 bar Reset Indicator
- 563234 - 69 bar Reset Indicator
- 563235 - 103 bar Reset Indicator
- 563236 - 138 bar Reset Indicator
- 563237 - 172 bar Reset Indicator
- 563231 - Ms Mh Reset Indicator w/ Memory, 250 PSI, 1/8 NPT(F) - Mj, Mxp Divider Valves
- 563233 - Ms Mh Reset Indicator w/ Memory, 750 PSI, 1/8 NPT(F) - Mj, Mxp Divider Valves
- 563234 - Ms Mh Reset Indicator w/ Memory, 1000 PSI, 1/8 NPT(F) - Mj, Mxp Divider Valves
- 563235 - Ms Mh Reset Indicator w/ Memory, 1500 PSI, 1/8 NPT(F) - Mj, Mxp Divider Valves
Part of a complete family of reset indicators with different pressure ratings for various system requirements Reset Indicators stop lube system operation when a fault occurs. They can be used in either master or secondary divider valves. A fault is indicated by a pin extending through the opening in the cap and is manually reset.
Reference Manuals
