GRACO 563241 - Reset Indicator w/ Memory, 750 PSI, 1/4 NPT(F) - Mx Divider Valves Only

GRACO 563241 Reset Indicator with Memory is a pressure-sensitive device that stops lube system operation when a fault occurs, protecting the lube system and locating line blockage. This indicator monitors working outlets of Trabon Centralized Lubrication Systems and provides quick response to protect against system failures.

Specifications

• Thread: 1/4 NPTF
• Max Working Pressure: 750 PSI
• Part Number: 563241 (509-932-030)
• Compatible Systems: MX only (not MXP)
• Type: Reset Indicator with Memory
• Application: MX Only

Features

• Stops lube system operation when fault occurs
• Memory function retains fault indication
• Quick response to protect lube system
• Locates lube line blockage
• Pressure-sensitive operation
• Can be used in master or secondary divider valves

Applications

• Monitoring working outlets of Trabon Centralized Lubrication Systems
• Progressive divider valve system protection
• Lube line blockage detection
• System fault indication

Compatible Equipment

• MX Divider Valves (not compatible with MXP)
• Trabon series progressive divider valve systems

Related Parts

• 563239 (509-932-010) - 250 PSI
• 563240 (509-932-020) - 500 PSI
• 563242 (509-932-040) - 1,000 PSI
• 563243 (509-932-050) - 1,500 PSI
• 563244 (509-932-060) - 2,000 PSI
• 563245 (509-932-070) - 2,500 PSI
• 563242 - Reset Indicator w/ Memory, 1000 psi, 1/4 NPT(F) - MX Divider Valves Only
• 563243 - Reset Indicator w/ Memory, 1500 psi, 1/4 NPT(F) - MX Divider Valves Only

Recommended for use to monitor every working outlet of a Trabon Centralized Lubrication System. When a lube line becomes blocked, high pressure moves pistons and compresses spring, pushing indicator pin through cap opening to signal fault. Reset Indicators stop lube system operation when a fault occurs. They can be used in either master or secondary divider valves. A fault is indicated by a pin extending through the opening in the cap and is manually reset.

Reference Manuals

• L15401EN-C (Page 1)
• 312497 (Page 38) Trabon Divider Valves .
