GRACO 564276 HP-50 Lubricator without Pumps or Options
Single plunger force feed design is highly efficient for injecting lubricants and/or compatible fluids into high pressure systems. Vacuum sight feeds on self-contained pumping units show output of lubricant to individual lubrication points.
For lubricating compressor and circulator cylinder walls, heavily loaded bearings and other moving parts.
Specifications
| Compatible Material | Oil |
| Maximum Drive Speed (RPM) | 36 |
| Maximum Fluid Viscosity (SUS) | 5000 |
| Maximum Number of Drops Per Stroke (drops/stroke) | 4 |
| Maximum Operating Temperature (°F) | 120 |
| Maximum Reservoir Capacity (gal) | 2.25 |
| Maximum Reservoir Capacity (pt) | 18 |
| Maximum Reservoir Capacity (qt) | 9 |
| Maximum Working Pressure (psi) | 50000 |
| Minimum Drive Speed (RPM) | 3 |
| Minimum Fluid Viscosity (SUS) | 100 |
| Minimum Number of Drops Per Stroke (drops/stroke) | 1 |
| Minimum Operating Temperature (°F) | -20 |
| Overall Depth (in) | 22.68 |
| Overall Height (in) | 14.77 |
| Overall Width (in) | 11.56 |
| Pump Size (in) | 1/4 |
| Reservoir Material | Cast Iron |
| Type | Box Lubricator |
| Compatible Material | Oil |
| Maximum Drive Speed (RPM) | 36 |
| Maximum Fluid Viscosity (SUS) | 5000 |
| Maximum Number of Drops Per Stroke (drops/stroke) | 4 |
| Maximum Operating Temperature (°C) | 49 |
| Maximum Reservoir Capacity (L) | 8.5 |
| Maximum Working Pressure (bar) | 3447 |
| Maximum Working Pressure (kPa) | 344700 |
| Minimum Drive Speed (RPM) | 3 |
| Minimum Fluid Viscosity (SUS) | 100 |
| Minimum Number of Drops Per Stroke (drops/stroke) | 1 |
| Minimum Operating Temperature (°C) | -29 |
| Overall Depth (cm) | 57.61 |
| Overall Depth (mm) | 576.1 |
| Overall Height (cm) | 37.5 |
| Overall Height (mm) | 375 |
| Overall Width (cm) | 29.36 |
| Overall Width (mm) | 293.6 |
| Pump Size (cm) | 0.6 |
| Pump Size (mm) | 6.3 |
| Reservoir Material | Cast Iron |
| Type | Box Lubricator |
GRACO 564276 HP-50 Lubricator without Pumps or Options
Single plunger force feed design is highly efficient for injecting lubricants and/or compatible fluids into high pressure systems. Vacuum sight feeds on self-contained pumping units show output of lubricant to individual lubrication points.
For lubricating compressor and circulator cylinder walls, heavily loaded bearings and other moving parts.
Specifications
| Compatible Material | Oil |
| Maximum Drive Speed (RPM) | 36 |
| Maximum Fluid Viscosity (SUS) | 5000 |
| Maximum Number of Drops Per Stroke (drops/stroke) | 4 |
| Maximum Operating Temperature (°F) | 120 |
| Maximum Reservoir Capacity (gal) | 2.25 |
| Maximum Reservoir Capacity (pt) | 18 |
| Maximum Reservoir Capacity (qt) | 9 |
| Maximum Working Pressure (psi) | 50000 |
| Minimum Drive Speed (RPM) | 3 |
| Minimum Fluid Viscosity (SUS) | 100 |
| Minimum Number of Drops Per Stroke (drops/stroke) | 1 |
| Minimum Operating Temperature (°F) | -20 |
| Overall Depth (in) | 22.68 |
| Overall Height (in) | 14.77 |
| Overall Width (in) | 11.56 |
| Pump Size (in) | 1/4 |
| Reservoir Material | Cast Iron |
| Type | Box Lubricator |
| Compatible Material | Oil |
| Maximum Drive Speed (RPM) | 36 |
| Maximum Fluid Viscosity (SUS) | 5000 |
| Maximum Number of Drops Per Stroke (drops/stroke) | 4 |
| Maximum Operating Temperature (°C) | 49 |
| Maximum Reservoir Capacity (L) | 8.5 |
| Maximum Working Pressure (bar) | 3447 |
| Maximum Working Pressure (kPa) | 344700 |
| Minimum Drive Speed (RPM) | 3 |
| Minimum Fluid Viscosity (SUS) | 100 |
| Minimum Number of Drops Per Stroke (drops/stroke) | 1 |
| Minimum Operating Temperature (°C) | -29 |
| Overall Depth (cm) | 57.61 |
| Overall Depth (mm) | 576.1 |
| Overall Height (cm) | 37.5 |
| Overall Height (mm) | 375 |
| Overall Width (cm) | 29.36 |
| Overall Width (mm) | 293.6 |
| Pump Size (cm) | 0.6 |
| Pump Size (mm) | 6.3 |
| Reservoir Material | Cast Iron |
| Type | Box Lubricator |
