GRACO 647731 Husky 1050 Series Air-Operated Double Diaphragm Transfer Pump for Oil Evacuation, Oil Transfer, BN/AC/TPE
Shown with optional 24D642 muffler
The Husky 1050 air-operated diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover. The one-piece center section eliminates leaks and reduces maintenance on Husky pumps when compared to other diaphragm pumps.
Specifications:
| Air Exhaust Port Size (in) | 3/4 |
| Air Exhaust Port Thread Gender | Female |
| Air Exhaust Port Thread Type | NPT |
| Air Inlet Size (in) | 1/2 |
| Air Inlet Thread Gender | Female |
| Air Inlet Thread Type | NPT |
| Application | Industrial |
| Ball Material | Acetal |
| Center Section Material | Aluminum |
| Compatible Material | Oil, Water, Antifreeze |
| Connection Type | Threaded |
| Diaphragm Material | TPE |
| Fluid Inlet Size (in) | 1 |
| Fluid Inlet Thread Gender | Female |
| Fluid Inlet Thread Type | NPT |
| Fluid Outlet Size (in) | 1 |
| Fluid Outlet Thread Gender | Female |
| Fluid Outlet Thread Type | NPT |
| Fluid Section Material | Aluminum |
| For Use With | Oil, Waste Oil |
| Manifold O-Ring Material | None |
| Material | Aluminum |
| Maximum Air Consumption (SCFM) | 25 |
| Maximum Air Pressure (MPa) | 0.7 |
| Maximum Air Pressure (psi) | 100 |
| Maximum Cycle Rate (CPM) | 280 |
| Maximum Flow Rate (GPM) | 50 |
| Maximum Fluid Pressure (MPa) | 0.7 |
| Maximum Fluid Pressure (psi) | 100 |
| Maximum Solid Size (in) | 0.125 |
| Overall Height (in) | 15.9 |
| Power Source | Air |
| Pump Ratio | 1:1 |
| Seat Material | Buna |
| Standards Met | UL |
| Type | Pneumatic Diaphragm Pump |
| Weight (lb) | 23 |
| Wetted Material | Aluminum, TPC-ET, Acetal, PTFE, Buna-N |
