GRACO 802072 - Pressure Gauge, 1/4 Nptm, 0-1500 PSI

Professional fluid pressure gauge designed for accurate pressure monitoring in fluid handling systems. Features a durable black case construction with bottom mount configuration for easy installation and reading in industrial applications.

Specifications

• Thread: 1/4 NPTM
• Max Working Pressure: 0-1500 PSI
• Material: Black case
• Gauge: 2-1/2" dial
• Mount Type: Bottom
• Connection: 1/4 NPTM
• Type: pressure gauge for fluid
• Finish: cst (carbon steel treatment)

Features

• 2-1/2 inch dial for easy reading
• Bottom mount configuration
• Durable black case construction
• 1/4 NPTM threaded connection
• 0-1500 PSI pressure range

Applications

• Fluid pressure monitoring
• Industrial fluid systems
• Spray equipment pressure monitoring
• Hydraulic system monitoring

Compatible Equipment

• GST package 232506
• GST package 232507
• 243159 - Module Pump Hydraulic
• Model 243502 35# Dynastar Pump Module
• Model 243503 120# Dynastar Pump Module
• Model 243504 400# Dynastar Pump Module

Related Parts

• 187875 - Stainless Steel Low Pressure Fluid Gauge, 1/4 Nptm, 0-30 PSI
• 101176 - Fluid Pressure Gauge
• 176455 - Fluid Pressure Gauge, 1/4 Nptm, 0-100 PSI
• 187874 - Stainless Steel Low Pressure Fluid Gauge, 1/4 Nptm, 0-100 PSI
• 187873 - Stainless Precision Fluid Pressure Gauge, 1/4 Nptm, 0-200 PSI
• 187876 - Stainless Steel Low Pressure Fluid Gauge, 1/4 Nptm, 0-300 PSI
• 208855 - Stainless Fluid Pressure Gauge w/ Dampener, 0-300 PSI, 1/4 Nptm
• 118338 - Fluid Pressure Gauge, 0-300 PSI, 1/8" Bspp, 1/8 Bspp
• 101696 - Fluid Pressure Gauge, 0–1000 PSI, 1/4" NPT Male, Bottom Mount

Part of GRACO's comprehensive fluid gauge family offering various pressure ranges and mounting configurations This is part 206 in the fluid pressure regulator assembly. There is also a stainless steel version (part 112564) available for the SST package 231964. Part is used in fluid pressure regulator systems - see manual 307886 for additional details. Listed as Reference No. 4r with quantity 1 in the parts list for Dynastar Pump Module systems

Reference Manuals

• 336834 (Page 4) Fluid Regulators List
• 308690 (Page 19) art-Mounted Air Assisted Packages
• 309098 (Page 13) 5:1 Dynastar Pump Module
• 312349 (Page 17) 10:1 DynaStar Pump Module Repair
• 3A3429 (Page 21) 10:1 Dyna-star Pump Module with Auto-Fill Shutoff, Instructions
