GRACO 96G280 - G3 Standard Hammer/Chisel Paste Lube Pump, 24 VDC, 4L, Low Level Relay, DIN
The Graco G3 Standard is an electric automatic lubrication pump that delivers metered shots of lubricant to multiple points on a programmed schedule. With no onboard controller, it runs from your existing machine control or PLC for a low-cost way to automate lubrication.
Key Features
Specifications
| Series | G3 Standard |
| Lubricant | Chisel paste (hydraulic breakers) |
| Reservoir Capacity | 4L |
| Input Voltage | 24 VDC |
| Reservoir Type | Standard |
| Low-Level Monitoring | Low-level relay output |
| Power Connector | DIN |
| Pump Elements | 1 adjustable element included (3 maximum) |
| System Compatibility | Injector-based and series progressive |
| Graco Model Code | G-24NC-4LHA00-0D00L000 |
Installation Notes
A pressure relief valve (Graco 16C807) is required at each pump outlet and is sold separately. DC models require a user-supplied fuse sized to the input voltage (fuse kits available from Graco). Mount the pump upright.
